- Page 2 ©2020 ADJ PRODUCTS LLC all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. ADJ logo and identifying product names and numbers herein are trademarks of ADJ PRODUCTS LLC. Copyright protection claimed includes all forms and matters of copyrightable materials and in- formation now allowed by statutory or judicial law or hereinafter granted.
-
Page 3: Table Of Contents
C O N T E N T S General Information Limited Warranty (USA Only) Safety Guidelines Maintenance Guidelines Panel Overview Receiver-Card Module Removal Handling and Transportation Installation Technical Specifications Optional Components and Accessories ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands... -
Page 4: General Information
Corner Protectors that safe-guard the corners when they are not connected. In addition, each Vision Series LED Video Panel model has magnets located at the top and bottom to allow users to temporarily connect two panels, let go, and then securely latch them on the rear. This allows a single-user to install a full wall of panels. -
Page 5: Limited Warranty (Usa Only)
All shipping charges must be prepaid. If the requested repairs or service (including parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay return shipping charges only to a designated point within the United States. If the entire instrument is sent, it must be shipped in its original package and packaging material. -
Page 6: Safety Guidelines
This VS LED Video Panel is a sophisticated piece of electronic equipment. To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual. ADJ is not responsible for injury and/or damages resulting from the misuse of this panel due to the disregard of the information printed in this manual. - Page 7 CAUTION: Test panel for 2-hours per week, if not used regularly or for an extended period of time. CAUTION: Cases used to transport panel must me properly waterproofed for transportation. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
-
Page 8: Maintenance Guidelines
/ rear), limit or remove any unit exposed to moisture, condensation, or humidity, and consider using air conditioning where available. 16. When not in use, store VS LED Video Panels in a dry, well ventilated facility. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands... -
Page 9: Panel Overview
Integrated Vertical Locking Panel Connector Integrated Horizontal Locking Panel Connector Locking RJ45 Ethernet Connect In/Out/RJ45 Power Output (-) Power Input (+) ESD Grounding Hole & Connection Plate Integrated Corner Protectors ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands... - Page 10 The cover of the power supply box can be secured to protect all internal accessories and components. All detachable component is secured with a safety cable. Note that panels and power supply cover are all attached with safety cables. 19.68” (500mm) ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
-
Page 11: Receiver-Card Module Removal
The magnet must be fully retracted in the Magnet Module Removal Tool before placing it against the Receiver-Card Module face, which is to prevent the magnet from snapping against the LEDs and damaging them. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands... - Page 12 When finished servicing the Reciever-Card Module, reverse the operation. Be sure to reattach the safety cable to the Reciever-Card Module. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
-
Page 13: Handling And Transportation
ESD precautions, to reduce static building friction, take care to lift the panels without rubbing the LED panel surface along the foam-covered slots, which can generate static electricity that can damage LEDs on VS LED Video Panels. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands... - Page 14 Panels, it is constructed from 9mm plywood and fitted with steel ball corners, aluminum edging, large swivel castors, professional butterfly latches, four sprung handles, and a hinged lid. VSFC8 Flight Case ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
-
Page 15: Installation
If you lack these qualifications, do not attempt the installation yourself. Improper installation can result in bodily injury and property damage. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands... - Page 16 Rotate handle down (counterclockwise) to cinch the horizontal tab-keyed connector in place. horizontal tab-keyed connector. To unlock, rotate handle (clockwise), releasing tension of horizontal tab-keyed connector cinching mechanism. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
- Page 17 Press the spring-loaded locking latch toward the corresponding alignment holes. left while pressing vertical connector up into locking-latch. Release latch to hold the vertical connector. To lock, twist vertical connector lever to the left. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
- Page 18 INSTALLATION – RIGGING BAR The VS LED Video Panel is compatible with ADJ’s VSRB1 Rigging Bar (sold separately), which easily and securely locks to the top of the first panel in a vertical hang of up to 20 VS LED Video Panels, allowing them hang from a truss, hoist, or lintel beam.
- Page 19 INSTALLATION – RIGGING BAR, VERTICAL HANG & STACK VERTICAL HANG VERTICAL STACK ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
- Page 20 Release latch to hold the vertical connector. To lock, twist vertical connector lever to the left. To unlock the vertical connector, rotate lever to the right (counter-clockwise), then press spring- loaded locking latch inward. The vertical connector will drop open. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
- Page 21 THE MAGNETS ARE NOT STRONG ENOUGH TO HOLD A PANEL WITHOUT ASSISTENCE. HOLD ONE LIFTING HANDLE AT ALL TIMES (WHILE MAINTAINING UPWARD PRESSURE), UNTIL PANEL IS LOCKED IN PLACE, STARTING WITH OPOSITE VERTICAL LOCK. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
- Page 22 ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
- Page 23 USE CAUTION WHEN INSTALLING THE VIDEO PANELS USING THE RIGGING BAR FOR STACKED ASSEMBLIES. IT IS NOT DESIGNED AS A FREESTANDING ASSEMLBY AND IS INHERENTLY UNSTABLE. STACKED LED VIDEO PANEL ASSEMBLIES MUST BE SECURELY INSTALLED BY QUALIFIED TECHNICIANS ONLY! ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
- Page 24 Rear Support Bracket: Use an VS1RSB Rear Support Bracket (sold separately) when connecting multiple panels for a larger display design, to strengthen the structural integrity of the screen, improve consistent flatness, and improve overall screen continuity. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
- Page 25 INSTALLATION – HORIZONTAL TRUSS MOUNT (OPTIONAL) The optional VSR210 Horizontal Truss Mounting Bracket (sold separately) allows for the horizontal (ceiling) installation of the VS LED Video Panels. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
- Page 26 VS Series LED Video Panel to VSRB1 Single Panel Rigging Bar The Back Plate can be loaded with sandbags to stabilize the stacked VS Series LED Video Panel structure ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
-
Page 27: Technical Specifications
10～90% RH No condensation Operating Humidity Operating Life 50000hours MTBF 5000hours Protection Level IP20 Out of Control Rate ≤0.02% Curve Angle Specifications subject to change without any prior written notice. ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands... -
Page 28: Optional Components And Accessories
CAT6PRO50 (50ft.) CAT6PRO100 (100ft.) CAT6PRO150 (150ft.) CAT6PRO25FC (25ft.) Panel to Panel Data Link Cables (Locking RJ45 Ethernet Connect In/Out CAT6PRO50FC (50ft.) to Locking RJ45 Ethernet Connect In/Out) CAT6PRO100FC (100ft.) ADJ Products, LLC • Los Angeles, Ca USA • Kerkrade, The Netherlands...
