Parameter
PROMLOC
PROMLOC selects the boot PROM location and size. NONE means that the boot
PROM is disabled. Make sure that the boot PROM location does not overlap any
memory in the system.
Parameter
CABLETYPE
CABLETYPE selects the interface type. DC-DC converter is enabled when THIN is
selected . TWISTEDLOW uses the twisted pair interface with a lower squelch level
for use with longer than normal cables.
5-7
Table 5- 6. PROMLOC Parameter
Parameter Values
None
C000-16K
C400-16K
C800-16K
CC00-16K
D000-16K
D400-16K
D800-16K
DC00-16K
C000-32K
C800-32K
D000-32K
D800-32K
C000-64K
D000-64K
.CABLETYPE Parameter
Table 5-7
Parameter Values
TWISTED
THIN
THICK
TWISTEDLOW
Chapter 5 - 16-Bit Ethernet Installation
Default
None
Default
TWISTED
