Installing the XVME-956/101
The XVME-956/101 is shipped with a special mylar insulator that protects
the battery connections. The installation of the XVME-956/101 is similar to
that of a Type B, which is explained in Section 1.3.4, with the exception of
the mylar insulator. Follow these steps to secure the XVME-956/101 mylar
insulator.
1. Secure the XVME-956/101 mylar insulator using nylon screws at posi-
tion 4 (shown in Figure 4-5).
2. Place the XVME-956/101 module on the XVME-976 making sure the
pins on the XVME-976 are aligned with the sockets on the XVME-
956/101.
3. Connect the battery cable from the front panel to the appropriate con-
nector on the XVME-956/101. Next, secure the front panel to the
XVME-976 using the two screws labeled 2 in Figure 4-5.
4. Fold the mylar insulator back over the XVME-956/101 and secure it to
the XVME-956/101with the screws labeled 3 in Figure 4-5.
5. Secure the mylar insulator and front panel battery assembly using screws
labeled 1 in Figure 4-5.
Figure 4-5 shows the mylar insulator and front panel assembly of the
XVME-956/101 memory expansion module.
Figure 4-5. XVME-956/101 Type A Module
