Xycom XVME-976 Manual page 20

Table 1-3. J12 Pinouts
Pin Name
1 +12V
3 TMS
5 TDI
7 GND
9 PCI-RSVD*
11 BUSMODE2*
13 RST*
15 +.3V
17 PCI-RSVD*
19 PAD(30)
21 GND
23 PAD(24)
25 IDSEL
27 +3.3V
29 PAD(18)
31 PAD(16)
33 GND
35 TRDY*
37 GND
39 PERR*
41 +3.3V
43 C_BD1*
45 PAD(14)
47 GND
49 PAD(8)
51 PAD(7)
53 +3.3V
55 PMC-RSVD
57 PMC-RSVD
59 GND
61 ACK64*
63 GND
Pin Name
2 TRST*
4 TDO
6 GND
8 PCI-RSVD*
10 PCI-RSVD*
12 +3.3V
14 BUSMODE3*
16 BUSMODE4*
18 GND
20 PAD(29)
22 PAD(26)
24 +3.3V
26 PAD(23)
28 pad(20)
30 gnd
32 C_BD2*
34 PMC-RSVD
36 +3.3V
38 STOP*
40 GND
42 SERR*
44 GND
46 PAD(13)
48 PAD(10)
50 +3.3V
52 PMC-RSVD
54 PMC-RSVD
56 GND
58 PMC-RSVD
60 PMC-RSVD
62 +3.3V
64 PMC-RSVD
Chapter 1 – Introduction
1-15
