Chapter 1 – Introduction
PMC Module Installation
The XVME-976 is designed to accept the installation of PMC expansion
modules to add PCI functionality.
Figure 1-5. XVME-976 with PMC Expansion Module
Note
The XVME-976 PMC site is keyed to accept only 5-volt boards.
Other voltage configurations will not fit on this site.
1-11
