Parts List - Linear Technology 1814A Demo Manual

parts List

ITEM QTY
1 1
2 1
3 1
4 1
5 2
6 4
7 2
8 1
9 1
10 1
11 1
12 4
13 4
14 2
15 2
16 1
17 4
18 1
19 8
20 1
21 1
22 4
23 2
24 1
25 1
26 1
DC1814A-A
1 1
2 4
3 1
4 1
DC1814A-B
1 1
2 4
3 1
4 1
DC1814A-C
1 1
2 4
3 1
4 1
DC1814A-D
1 1
2 4
3 1
4 1
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE PART DESCRIPTION
C1 CAP , 0603 0.1µF 10% 25V X7R
C2 CAP , 4.7µF 20% 63V ALUM.
C5 CAP , 1206 0.22µF 20% 100V X7R
C4 CAP , 1210 1.0µF 10% 100V X7R
C3, C6 CAP , 1808 1000pF 10% 2KV X7R
CT1-CT4 CAP , 0805 0.01µF 5% 100V X7R
D4, D5 DIODE, RECTIFIER, 100V 1A, SMA
D3 DIODE, TVS 58V 400W SMA
D2 DIODE, TVS, 64V 600W SMB
D1 DIODE, ZENER 3.9V SOD-123
D23 DIODE, ZENER 5.6V 5% SOT23
E1-E4 TESTPOINT, TURRET, 0.094" PBF
F7-F10 FUSE, 3A, 63VDC 1206
J3, J4 CONN, JACK, BANANA
J1, J2 CONN, RJ45, SINGLE PORT
R10 RES, 0603 1.0Ω 5% 1/10W
R6-R9 RES, 0603 10k 5% 1/10W
R5 RES, 0603 100k 5% 1/10W
R1-R4, RT1-RT4 RES, 0603 75Ω 5% 1/10W
R11 RES, THICK FILM 0805 1.0k 5% 1/4W
RS1 RES, 2512 0.25Ω 1% 2W
MH1-MH4 STAND-OFF , NYLON 0.75"
SW1, SW2 SWITCH, MOMENTARY PUSHBUTTON
Q1 XSTR, MOSFET, N-CHANNEL 100V 2.3A POWER-33
Q2 XSTR, PNP , 300V 500MA SOT23 CMPTA92
T1 XFMR, POE+ 1.5A
(Option)
DC1814A GENERAL BOM
FB1-FB4 FERRITE BEAD, 1k, 0805
U1 IC, LTC4274A-1, SINGLE PORT 38.7W PSE CONTROLLER
FAB, PRINTED CIRCUIT BOARD
DC1814A GENERAL BOM
FB1-FB4 FERRITE BEAD, 1k, 0805
U1 IC, LTC4274A-2, SINGLE PORT 52.7W PSE CONTROLLER
FAB, PRINTED CIRCUIT BOARD
DC1814A GENERAL BOM
FB1-FB4 FERRITE BEAD, 1k, 0805
U1 IC, LTC4274A-3, SINGLE PORT 70W PSE CONTROLLER
FAB, PRINTED CIRCUIT BOARD
DC1814A GENERAL BOM
FB1-FB4 FERRITE BEAD, 1300Ω, 1812
U1 IC, LTC4274A-4, SINGLE PORT 90W PSE CONTROLLER
FAB, PRINTED CIRCUIT BOARD
DEMO MANUAL
DC1814A
MANUFACTURER/PART NUMBER
TDK C1608X7R1E104K (BAL. FR#1807)
PANASONIC, EEEFK1J4R7R
AVX 12061C224MAT
AVX, 12101C105KAT
TDK C4520X7R3D102K
AVX 08051C103JAT
VISHAY S1B
DIODES INC., SMAJ58A-13-F
DIODES INC., SMBJ64A-13-F
ON SEMI MMSZ4686T1G
FAIRCHILD, BZX84C5V6
MILL-MAX, 2501-2-00-80-00-00-07-0
BEL FUSE C1Q 3
KEYSTONE 575-4
STEWART CONN., SS-7188S-A-NF
VISHAY CRCW06031R00JNEA
YAGEO, RC0603JR-0710KL
YAGEO, RC0603JR-07100KL
YAGEO, RC0603JR-0775RL
PANASONIC, ERJ-P06J102V
STACKPOLE, CSRN2512FKR250
KEYSTONE, 8834(SNAP ON)
WÜRTH, 434 123 050 816
FAIRCHILD FDMC86102
CENTRAL SEMI CMPTA92
WÜRTH ELECTRONICS, 749022016
COILCRAFT ETH1-460L
TDK MPZ2012S102A
LINEAR LTC4274AIUHF-1
DEMO CIRCUIT 1814A
TDK MPZ2012S102A
LINEAR LTC4274AIUHF-2
DEMO CIRCUIT 1814A
TDK MPZ2012S102A
LINEAR LTC4274AIUHF-3
DEMO CIRCUIT 1814A
TAIYO YUDEN FBMH4532HM132-T
LINEAR LTC4274AIUHF-4
DEMO CIRCUIT 1814A
dc1814afe
7
