9: Replacing GSN Parts
Tools Needed to Replace Electrodes
Before starting the process of replacing an electrode, gather the tools that will be
needed.
Pictured in Figure 9-2, the tools are as follows (top right, clockwise):
• 1.5 mm. Allen wrench
• needle-nose pliers
• pin extraction tool (Hypertronics)
• slot-head screwdriver
In addition, a roll of electrical tape and scissors for cutting the tape are needed.
90
Figure 9-2. Tools needed for replacing electrodes
