Sensor To 256-Pin Plug - Geodesic Sensor Net Technical Manual

Sensors
1–10
1
2
3
4
5
6
7
8
9
10
Sensors
41–50
41
42
43
44
45
46
47
48
49
50
Geodesic Sensor Net Technical Manual
Table C-3. Sensor to 256-pin plug
256-channel GSN
Sensors
Pin 11–20 Pin
1A 11 2A
1B 12 2B
1C 13 2C
1D 14 2D
1E 15 2E
1F 16 2F
1G 17 2G
1H 18 2H
1J 19 2J
1K 20 2K
Sensors
Pin 51–60 Pin
5A 51 6A
5B 52 6B
5C 53 6C
5D 54 6D
5E 55 6E
5F 56 6F
5G 57 6G
5H 58 6H
5J 59 6J
5K 60 6K
S-MAN-200-GSNR-001 • January 31, 2007
Sensors Sensors
21–30 Pin 31–40
21 3A 31
22 3B 32
23 3C 33
24 3D 34
25 3E 35
26 3F 36
27 3G 37
28 3H 38
29 3J 39
30 3K 40
Sensors Sensors
61–70 Pin 71–80
61 7A 71
62 7B 72
63 7C 73
64 7D 74
65 7E 75
66 7F 76
67 7G 77
68 7H 78
69 7J 79
70 7K 80
C: GSN Pinouts
Pin
4A
4B
4C
4D
4E
4F
4G
4H
4J
4K
Pin
8A
8B
8C
8D
8E
8F
8G
8H
8J
8K
135
