Table B-3 is a guide to the sensor layouts contained in this appendix. The thick blue
lines in each layout indicate proper thumb placement for the initial application (see
Table 6-1 on page 65).
Geodesic Sensor Net Technical Manual
Table B-3. Sensor layouts
Page number
page 123
32-channel HCGSN v.1.0
page 124
64-channel HCGSN v.1.0
page 125
128-channel HCGSN v.1.0
page 126
256-channel HCGSN v.1.0
page 127
64-channel GSN 200 v.2.0
page 128
128-channel GSN 200 v.2.1
page 129
256-channel GSN 200 v.2.1
Figure B-1. 32-channel HCGSN v.1.0
S-MAN-200-GSNR-001 • January 31, 2007
B: Net Sizing and Sensor Layouts
Sensor layout
123
