Gsn 200 (256-Channel Model); Gsn 200 (128-Channel Model), Without Wire Management - Geodesic Sensor Net Technical Manual

3: GSN 200
views of the GSN 200. Most of the wire management is done manually, by grouping
wires together with plastic stays.
Hypertronics
connector
Sensor
array
Cord lock for eye and
ear electrode bands
Cord lock for chin strap
Side
40
Chin
strap
Figure 3-2. GSN 200 (256-channel model)
Nasion
Figure 3-3. GSN 200 (128-channel model), without wire management
Geodesic Sensor Net Technical Manual
Cord lock for eye and
ear electrode bands
Front
Sensor lead
bundle
Sliding wire
guide
Cord lock for eye and
ear electrode bands
Back
S-MAN-200-GSNR-001 • January 31, 2007
