USB Stick as a Data Logger and for Updating Invert-
er Software
USB Flash Drive A USB flash drive connected to the USB A socket can act as a data logger for an inverter.
as a Data Logger
The logging data that is saved on the USB flash drive can be viewed directly in third-party
applications (e.g., Microsoft® Excel) at any time via the included CSV file.
Older Excel versions (up to Excel 2007) have a row limit of 65536.
Data on the USB If the USB thumb drive is used as a datalogger, three files are automatically created:
thumb drive
-
-
-
USB_Drive (1)
Data structure on the USB thumb drive
Structure of the CSV file:
FRONIUS.sys system file:
This file saves information from the inverter that is irrelevant to the customer. The file
must not be deleted separately. Only delete all files together (sys, fld, csv).
DALO.fld log file:
Log file for reading out data in Fronius Solar.access.
You can find additional information on the Fronius Solar.access software in the "DAT-
COM Detail" Operating Instructions at http://www.fronius.com
DATA.csv log file:
A log file for reading out data in a spreadsheet program (e.g., Microsoft® Excel)
GALVO / SYMO / PRIMO / ECO
01 (3)
FRONIUS.sys
DALO.fld
DATA.csv
02
FRONIUS.sys
DALO.fld
DATA.csv
(1) (2)
(1) USB root directory
(2) Fronius inverter (Fronius Galvo,
Fronius Symo Advanced, Fronius
Primo, or Fronius Eco)
(3) Inverter number – can be set in the
(2)
setup menu under DATCOM
If multiple inverters exist with the same in-
verter number, the three files are saved in
the same folder. A number is appended to
the file name (e.g., DALO_02.fld)
(3) (4) (5) (6) (7)
