Fronius Symo - Installation
10.0-3 208-240 / 12.0-3 208-240
10.0-3 480 / 12.5-3 480
15.0-3 208
15.0-3 480 / 17.5-3 480
20.0-3 480 / 22.7-3 480
24.0-3 480
42,0426,0202,EA 007-24082017
Solar Energy
Installation Instructions
Inverter for grid-connected photo-
voltaic systems

Advertisement

Table of Contents
loading

Related Manuals for Fronius 10.0-3 208-240

Summary of Contents for Fronius 10.0-3 208-240

  • Page 1 / Perfect Charging / Perfect Welding / Solar Energy Installation Instructions Fronius Symo - Installation 10.0-3 208-240 / 12.0-3 208-240 Inverter for grid-connected photo- voltaic systems 10.0-3 480 / 12.5-3 480 15.0-3 208 15.0-3 480 / 17.5-3 480 20.0-3 480 / 22.7-3 480 24.0-3 480...

  • Page 3: Table Of Contents

    Safety..............................Permitted Cables ..........................Connecting Aluminum Cables....................... Monitoring the Grid ..........................Fronius Symo 15.0-3 208 – ferrite ring ....................Connecting the inverter to the public grid (AC) ..................Maximum AC Fuse Protection ......................Additional external AC and/or DC disconnect..................String Fuses...............................
  • Page 4 Buffer Memory ............................Suitable USB Sticks ..........................USB Stick for Updating Inverter Software..................... Removing the USB Stick........................Notes on Maintenance ..........................Maintenance ............................Cleaning..............................

  • Page 5: Location Selection And Installation Position

    Location selection and installation position Explanation of DANGER! Indicates an immediate danger. Death or serious injury may result if Safety Instruc- appropriate precautions are not taken. tions WARNING! Indicates a possibly dangerous situation. Death or serious injury may result if appropriate precautions are not taken. CAUTION! Indicates a situation where damage or injury could occur.

  • Page 6: Intended Use

    Only put the inverter into operation with the fixing screws securely tightened. NOTE! Fronius will not bear any costs for production downtimes, or for installa- tions, etc., which may arise due to a detected electric arc and its consequences. Fronius accepts no liability for fires which may break out despite integrated arc detection/interruption (e.g., due to a parallel arc).
  • Page 7 The inverter is suitable for indoor installation. The inverter is suitable for outdoor installation. Because of its NEMA 4X protection class, the inverter is not susceptible to hose water on any side and can also be operated in moist environ- ments.

  • Page 8: Installation Position Of The Inverter

    The inverter is designed to be dustproof in principle. However, in areas of high dust accumulation, the cooling surfaces can become dusty, which can impair the thermal performance. In this case, the dust must be re- moved regularly. We therefore recommend that installation is not carried out in areas and environments with high dust accumulation.

  • Page 9: General Location Selection

    Do not install the inverter with the connections upwards on a vertical wall or column. Do not install the inverter overhanging with the connections upwards. Do not install the inverter overhanging with the connections downwards. Do not install the inverter on the ceiling. General location Please note the following criteria when choosing a location for the inverter: selection...

  • Page 10: Example: Installation Of Several Inverters

    When installing the inverter in a switch cabinet or similar closed environment, it is neces- sary to make sure that the hot air that develops will be dissipated by forced-air ventilation. If you wish to install the inverter on the outer walls of cattle stables, it is important to keep a minimum clearance of 2 m between all sides of the inverter and air vents and other openings.

  • Page 11: Attaching The Mounting Bracket

    Attaching the Mounting Bracket Safety WARNING! An electric shock can be fatal. Danger of residual voltage from ca- pacitors. Wait until the capacitors have discharged. Discharge takes five minutes. CAUTION! The inverter can be damaged by soiling or water on the terminals and contacts of the connection area.

  • Page 12: Installing The Wall Bracket On A Wall

    Installing the wall The wall bracket must be secured in at least four places. bracket on a wall NO NEMA ENCLOSURE TYPE Al / St 0.2 - 0.3 in. (6 - 8 mm)

  • Page 13: Install Mounting Bracket On A Mast Or Beam

    Install mounting For installation of the inverter on a mast or bracket on a mast beam, Fronius recommends using the "Po- or beam le clamp" (order no. SZ 2584.000) mast mounting kit from Rittal GmbH. The kit can be used to mount the inverter on round or rectangular masts with the follo- wing diameters: from 40 to 190 mm...

  • Page 14: Knockouts

    Knockouts Safety NOTE! When using the cable inlets at the back, take care to seal them according to protection class NEMA4X before operating outdoors. NOTE! When installing outdoors, only use waterproof conduit fittings and con- duits. Conduit fittings and conduits are not part of the scope of supply for the in- verter.

  • Page 15: Knock Or Drill Out Knockouts

    Knock or drill out IMPORTANT! The knockouts on the underside of the wall bracket may be knocked out us- knockouts ing a hammer or screwdriver, drilled out using a step drill or opened using a hole punch. The side knockouts and the knockouts at the back may only be drilled out with a step drill or opened with a hole punch.

  • Page 17: Suitable Grids

    Inverters can be operated in the following grids: Delta No neutral conductor Setup: Nominal voltage: Appropriate inverter: 208 V Symo 10.0-3 208-240 / 240 V 12.0-3 208-240 / 15.0-3 208 220 V 220 V 50 Hz 50 Hz 208–240 V...

  • Page 18: Connecting The Inverter To The Public Grid (Ac)

    Connecting the inverter to the public grid (AC) Safety WARNING! An electric shock can be fatal. Inadequately sized electrical compo- nents can cause serious injury and damage to property. All electrical connections must be made in accordance with the National Electrical Code, ANSI/NFPA 70, and any other regulations applicable to the installation site.
  • Page 19 UL; connection possible with ferrules only use stranded PV (ZKLA) or 2-wire not inspected as per UL; connection possible; AWG 16 with ferrules only Minimum AWG as per NEC 10.0-3 208-240 12.0-3 208-240 15.0-3 208 208 V AWG 10/AWG 10...

  • Page 20: Connecting Aluminum Cables

    Fronius Symo 15.0-3 208 – fer- With Fronius Symo 15.0-3 208, the three rite ring phases and neutral conductor must be fed through a ferrite ring. The ferrite ring is in- cluded in the scope of delivery for the inver- ter.
  • Page 21 16 lbf.in 1.8 Nm 0.6 in. (15 mm) AC ~ max. 80 A ≥ 100 mA ΔN § National Standards Type A If AC cables are laid over the shaft of the DC main switch or across the DC main switch connection block, the cables may be damaged when the inverter is pivoted or the inverter may not be able to be pivoted.

  • Page 22: Maximum Ac Fuse Protection

    100 mA is generally sufficient in this case. However, false alarms can be triggered for the residual current circuit breaker type A in individual cases and depending on local conditions. For this reason, Fronius recommends that you use a residual current circuit breaker suitable for frequency converters.

  • Page 23: String Fuses

    Only applies to device type Fronius Symo 15.0-3 208 and device types Fronius Symo 15.0-3 480 / 20.0-3 480 / 22.7-3 480 / 24.0-3 480 with the "Ecofuse" option: The use of string fuses in the Fronius Symo provides additional fuse protection for solar modules.

  • Page 24: Notes On The Multi-Mpp Tracker Inverter

    Notes on the Multi-MPP Tracker inverter Multi MPP Track- Multi MPP Tracker inverters have two inde- er – inverter pendent DC inputs (MPP Tracker). These PV 1 PV 1 PV 2 inputs can be connected to a number of dif- ferent modules.

  • Page 25: Connecting Solar Module Strings To The Inverter (Dc)

    Maintenance and service work on the inverter power stage set should only be carried out by Fronius-trained service technicians. WARNING! An electric shock can be fatal. Inadequately sized electrical compo- nents can cause serious injury and damage to property.

  • Page 26: General Information About Solar Modules

    Note the temperature coefficients in the solar module data sheet More exact data for sizing the solar module for the particular location can be obtained using calculation tools such as the Fronius Configuration Tool (available at https:// www.solarweb.com). See NEC table 690.7 for the appropriate voltage adjustment factor for crystalline sili- con solar modules, or use the manufacturer’s specified voltage coefficients.

  • Page 27: Connecting Solar Module Strings To The Inverter (Dc)

    NOTE! Take into account local specifications when configuring cable cross sec- tions. Connection Requirements: Carefully clean off the oxide layer of the stripped end of the cable, e.g., using a knife. IMPORTANT Do not use brushes, files or sandpaper. Aluminum particles may get stuck and can transfer to other cables.
  • Page 28 B A S I C M P P T R A C K E R 2 O F F option 12x 1.8 Nm / 16 lbf.in 42,0201,4479 42,0201,4480 42,0201,4480 42,0201,4479 6-21 mm² / 10-4 AWG / Al/Cu 5.5 Nm / 48.6 lbf.in 10.0-3, 12.0-3 208-240 / 10.0-3, 12.5-3 480 max.

  • Page 29: Data Communication

    Data communication Lay data commu- IMPORTANT! Only one Fronius Datamanager in master mode is permitted per Fronius nication cables Solar Net Ring. Switch other Fronius Datamanagers to slave mode or remove them. 22 lbf.in 2.5 Nm...

  • Page 30: Install Data Manager In Inverter

    IMPORTANT! Follow general ESD guidelines when handling option cards. IMPORTANT! Only one Fronius Datamanager in master mode is permitted per Fronius Solar Net Ring. Switch other Fronius Datamanagers to slave mode or remove them. Unused option card slots can be closed by replacing the cover (item number 42,0405,2094), or an inverter without Fronius Datamanager (light version) can be used.
  • Page 31 TX20 10.6 lbf.in 1.2 Nm...

  • Page 32: Clipping The Inverter Onto The Mounting Bracket

    Clipping the Inverter onto the Mounting Bracket Clipping the In- WARNING! An inadequate ground conductor connection can cause serious inju- verter onto the ry and damage to property. The housing screws provide an adequate ground con- Mounting Bracket ductor connection for grounding the housing and should not be replaced under any circumstances by other screws that do not provide a reliable ground conduc- tor connection.
  • Page 33 Lock 22.1 lbf.in / 2.5 Nm 4.3 in. 22.1 lbf.in 2.5 Nm...
  • Page 34 Lock...

  • Page 35: Seal Conduits

    Seal Conduits NOTE! Condensation in the con- duits can damage the inverter or the photovoltaic system compo- nents. Outside Inside To avoid undesirable air circula- tion and condensation in the con- duits: seal all conduits in use with a permanently elastic sealant seal every incoming and out- Conduit going conduit...

  • Page 36: Using For The First Time

    HI2 (Hawaii 208 V with NL-Mon) * For more information about “Field Adjustable Trip Points” and “Special Purpose Utility-Interactive” see www.fronius.com/QR-link/42042102339 C O N F I G L o a d i n g C o u n t r y S e t u p...
  • Page 37 S E T U P B A S I C A u t o D a y l i g h t s a v i n g M P P T R A C K E R 2...

  • Page 38: Options

    Options Options NOTE! A DIN rail is provided in order to mount accessory electri- cal devices including, but not limit- ed to, overcurrent protection, metering, radio or cellular modem. Maximum size for mounting of all devices is 4w x 4,75l x 2,75 inch- es.

  • Page 39: Notes On Software Updates

    Notes on Software Updates Notes on the soft- If the inverter is supplied with a USB flash ware update drive, the inverter software must be up- dated after starting up the inverter. Insert the USB flash drive in the data communication area of the inverter Call up the setup menu Select the "USB"...

  • Page 40: Field Adjustable Trip Points

    Field Adjustable Trip Points 208–240 setups Setup 208/Setup 208N Setup 240/Setup 240N Clearing Time [s] Clearing Time [s] Clearing Time [p] Clearing Time [p] V outer limit min 0.16 0.16 V inner limit min V outer limit max V inner limit max 0.16 0.16 V outer limit MIN...
  • Page 41 Setup 220/Setup 220N Setup BR N/Setup BR Clearing Time [s] Clearing Time [s] Clearing Time [p] Clearing Time [p] V outer limit MIN 60–126 0.016–21.0 60–126 0.016–21.0 adjustable 1–1260 1–1260 V outer limit MAX 128–166 0.016–21.0 128–166 0.016–21.0 adjustable 1–1260 1–1260 Setup 50 HZ/Setup 50 HN Clearing Time [s]...
  • Page 42 Setup 50HN Setup HI3 Clearing Time [s] Clearing Time [s] Clearing Time [p] Clearing Time [p] V outer limit max V inner limit max 0.16 0.16 V outer limit MIN 120–252 0.016–21.0 120–275 0.016–21.0 adjustable 1–1050 1–1260 V outer limit MAX 251–332 0.016–21.0 127–332...
  • Page 43 AC voltage Unit: seconds Unit: cycles (1) Nominal voltage F Inner Limit min (min. inner limit frequency) Imin F Inner Limit max (max. inner limit frequency) Imax F Outer Limit min (min. outer limit frequency) Omin F Outer Limit max (max. outer limit frequency) Omax Default set values: U <...

  • Page 44: Special Purpose Utility-Interactive

    Special Purpose Utility-Interactive This unit has been evaluated according to IEEE1547 and IEEE1574.1 utility interconnection protective functions. When "Special Purpose Utility-Interactive" (SPUI) setup is activated, the inverter no longer complies with these standards because the islanding function is disabled, the frequency and voltage-dependent power reduction is activated, and the frequency and voltage limits are changed.
  • Page 45 Setup MG5N Setup MG6 Clearing Time [s] Clearing Time [s] Clearing Time [p] Clearing Time [p] V outer limit min 0.56 V inner limit min 0.56 V outer limit max 0.56 V inner limit max 0.56 V outer limit MIN 120–252 0.016–21.0 120–275...

  • Page 46: Usb Stick As A Data Logger And For Updating Inverter Software

    Only delete all files together (sys, fld, csv). DALO.fld log file: Log file for reading out data in Fronius Solar.access. You can find additional information on the Fronius Solar.access Software in the "DAT- COM Detail" operating instructions at http://www.fronius.com DATA.csv log file: A log file for reading out data in a spreadsheet program (e.g., Microsoft®...

  • Page 47: Data Quantity And Memory Capacity

    Inverter no. Inverter type (DATCOM code) Logging interval in seconds Energy in watt-seconds with reference to the logging interval Inductive reactive power Capacitive reactive power Averages over the logging interval (AC voltage, AC current, DC voltage, DC cur- rent) Additional information Data Quantity and One USB stick with a memory capacity of 1 GB, for example, can record logging data at a Memory Capacity...

  • Page 48: Suitable Usb Sticks

    FAT16 FAT32 Fronius recommends that the USB stick only be used for recording logging data or for up- dating the inverter software. USB sticks should not contain any other data. USB symbol on the inverter display, e.g., in the "NOW" display mode:...

  • Page 49: Removing The Usb Stick

    Removing the Safety information for removing a USB stick USB Stick IMPORTANT! To prevent a loss of data, the connected USB stick should only be Do not disconnect removed under the following conditions: USB-Stick via the SETUP and "Safely remove USB / hardware"...

  • Page 50: Notes On Maintenance

    Notes on Maintenance Maintenance NOTE! For horizontal installation positions and when installing outside: check once per year that all screws are secured tightly. Maintenance and repair work must only be carried out by authorised personnel. Cleaning The inverter and the display can be cleaned with a damp cloth if necessary. Do not use any cleaning agents, abrasive cleaners, or solvents to clean the inverter.
