Summary of Contents for WhatsGPS S18
- Page 1 2G Vehicle GPS Tracker Model:S18 User Manual...
-
Page 2: Installation Instructions
Installation instructions... -
Page 3: Install Sim Card
Install SIM card Open the face cover and insert the SIM card in the right direction as shown in the picture below (note: insert SIM card must be done in shutdown state) Fill in the mobile phone number in the box below, so that you can recharge later or check the working status of the locator. -
Page 4: Switch On/Off
Switch on/off Switch on: When the terminal is turned ON for the first time, in the shutdown state, turn the switch to the ON position. GSM(green) light and GPS (blue) light of the host slowly flash to indicate normal startup. The GPS module starts to search for signals. -
Page 5: Installation Site
Login monitoring interface and install mobile APP Please log in the dealer designated location service platform for corresponding Settings and functional operations. Account: IMEI (in the sticker) Password: 123456 Please log in the dealer's designated website to download the mobile client software for installation Installation site The GPS antenna of the positioner is on the front of the main engine, try to make sure that the main engine is... - Page 6 Notice : 1. The magnet on the back of the product cannot be directly exposed to high temperature, such as the exhaust pipe of the car, or the magnet will fail. 2. The phone card in the device needs to be paid regularly, and the device cannot be monitored offline due to the arrears.
- Page 7 Functions Functions Specifications Timed return Timing return, according to the mode set time return position data Set a time point and choose a day or days of the week to send Week pattern location data after sleep Up to 4 groups of wake up time can be set every day.
- Page 8 Parameter Model：S18 Location Type：GPS/BDS/LBS positioning Checking method：PC/IOS/Android Frequency ：850/900/1800/1900 Antenna：GSM Alarm：Fence alarm, Overspeed alarm,Disassemble alarm GPS：GPS/BDS GPRS：CLASS B Battery：3.3V/4200mAh Standby time：3 year Size：73*42*31mm Weight：100G Working temperature：-25°C~75°C...
-
Page 9: Battery Safety Instructions
Battery safety instructions If you feel abnormal when operating the device, please refer to the following problems and solutions. If you cannot solve the problem, please contact the seller or service provider Please use the battery specified by the original factory of your terminal. -
Page 10: Troubleshooting
Troubleshooting 1. The terminal has been unable to connect to the background server after the first installation. The background display is not online. 1) check whether the main power supply wiring is correct, pay attention not to connect to the internal control line of the car;... - Page 11 3) check the installation position of the equipment, and make the GPS antenna face outwards, not towards the metal surface or wires; 4) the GPS signal will be weakened when surrounding tall buildings block it. Please drive to a place with open sky to locate it.
-
Page 12: Warranty Card
Warranty card Maintenance record Maintenance shop Sending date Fault description Maintenance situation IMEI number Maintenance person Maintenance record Maintenance shop Sending date Fault description Maintenance situation IMEI number Maintenance person...
