Attach pull-up bar

1. Select an appropriate height for the pull-up bar
2. Insert Twist Pin (8) through the back of the upright into the Pull-up Bar (7) and tighten (do not
fully tighten)
3. Rotate the Pull-up Bar up to the other upright and repeat
4. Your Pull-up Bar can now be rotated down when not in use, and can be tightened to reduce
movement when in use

Fold away

1. Undo one of the Twist Pins (8) holding up the pull-up bar and loosen the other Twist Pin (8),
then gently rotate the bar down flat to the upright
2. Pull out the Hitch Pins (12) from all four cross members
3. Lift the uprights slightly and rotate them inward
4. Replace all Hitch Pins (12) into Hole X (and through the cross member) for the right upright,
and Hole Z (and through the cross member) for the left upright, in order to lock the rack in the
stowed position
W
X Y Z
W
X Y Z
8
7
Set #1
Set #2
support@prxperformance.com
12
8
