The 90" Fold-in Murphy Rack is made by the creators of the original Profile
®
Folding Rack at PRx Performance
and is Patent Pending. An up-to-date record
of patents and patent pending items can be found at:
prxperformance.com/pages/prx-performance-patents-and-trademarks
For further installation assistance:
prxperformance.com/pages/murphy-rack
Advertisement
Table of Contents
Related Manuals for PRx Performance Murphy Rack
Summary of Contents for PRx Performance Murphy Rack
- Page 1 Powered by ® The 90” Fold-in Murphy Rack is made by the creators of the original Profile ® Folding Rack at PRx Performance and is Patent Pending. An up-to-date record of patents and patent pending items can be found at: prxperformance.com/pages/prx-performance-patents-and-trademarks...
- Page 2 90” Fold-in Murphy Rack All Parts & Tools Needed Item Description Tools Needed Rack Specifications 1A & 1B Top/Bottom Uprights Cordless Drill Upright Plate Folded: Level C Bracket 49” x 90” x 6.75” Pencil Wall Plate Plumb line Cross Member...
- Page 3 Locate studs Notes when mounting 1. The Murphy Rack is designed to be mounted to wooden studs with standard 16” or 24” spacing, with or without drywall 2. For mounting your rack to a wall with non-standard stud spacing, we typically recommend using a stringer board.
- Page 4 Attach cross members to uprights 1. Attach cross members to the lower and upper part of the upright according to primary athlete’s height. It is recommended to attach the lower Cross Member (5) below the athlete’s knees, and the upper cross member slightly above eye level. Refer to chart for approximate heights according to hole placement on the upright * Note: Bottom of uprights have hard rubber foot plugs 2.
- Page 5 Determine wall bracket heights 1. Once the cross members are attached to the uprights, set one upright against the wall (as it will be when in use) and align with one of the outermost studs. 2. With both cross members (of the same upright) flush to the wall, take a pencil and mark where the bottom of each cross member touches the wall 3.
- Page 6 Mount wall brackets Lower wall bracket 1. Beginning with the right stud, measure 1.75” up from the mark of each of the bottom cross members, and drill a pilot hole into the stud 2. Fasten a wall bracket to this stud with a 1/2” Lag Screw (15) and 1/2” Washer (16), but do not fully tighten 3.
- Page 7 Attaching cross member arms to wall bracket Determine which set of holes to attach the cross member arms to (PRx Performance recommends Set #2) 1. Use Set #1 if you do not have, or do not intend to get, the PRx Wall-Mounted Folding Bench. This allows the uprights to be nearly flush to the wall when folded in 2.
- Page 8 Attach pull-up bar 1. Select an appropriate height for the pull-up bar 2. Insert Twist Pin (8) through the back of the upright into the Pull-up Bar (7) and tighten (do not fully tighten) 3. Rotate the Pull-up Bar up to the other upright and repeat 4.
- Page 9 ® Folding Bench You can find the PRx Wall-Mounted Folding Bench at prxperformance.com The PRx Performance Folding Bench easily folds out for use, and folds flat to the wall when stored Product Description: 1. Bench Length 45” 2. Bench Width 12”...
- Page 10 Free workout programs! Scan the code or follow the Compete against others! link to download the app. http://onelink.to/xfvf5f Looking for accessories for you new rack? Check them out at PRx Performance! prxperformance.com/collections/murphy-rack-accessories support@prxperformance.com...
- Page 11 PRx Performance LLC warrants to the original consumer purchaser that this product will be free of defects in material and workmanship for one (1) year from the date of purchase. PRx Performance will repair or replace the product, at our sole option, in the event of such a defect within the warranty period.
