PRx Performance GRIND FITNESS A1000 User Manual

Power rack exerciser
Hide thumbs

Advertisement

Quick Links

Download this manual
GRIND FITNESS
POWERED BY PRX PERFORMANCE
We are an obsessed group of lifters who believe
that access to out-of-this-world equipment and
extraordinarily effective programming shouldn't
be limited to the filthy rich.
Our equipment only works if you GRIND.
Download the app and get to work.
POWER RACK EXERCISER
USER'S MANUAL
A1000 — MODEL NO. GR130
!
WARNING
Read the assembly, installation, care, maintenance, and use instructions in this manual
prior to assembling and using this equipment. Save this manual for future reference.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the GRIND FITNESS A1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PRx Performance GRIND FITNESS A1000

Summary of Contents for PRx Performance GRIND FITNESS A1000

  • Page 1 GRIND FITNESS POWERED BY PRX PERFORMANCE We are an obsessed group of lifters who believe that access to out-of-this-world equipment and extraordinarily effective programming shouldn't be limited to the filthy rich. Our equipment only works if you GRIND. Download the app and get to work.
  • Page 2 GET YOUR WORKOUTS! SCAN ME How you’ll feel after 30 days How you feel now https://thegrindfitness.com/a1000 FREE on the GRIND App* *It only works if you GRIND!

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS To reduce the risk of serious injury, read all important precaustions and instructions in this manual and all warnings on the rack before using the weight rack. GRIND assumes no responsibility for personal injury or property damage sustained by or through the use of this product. 1.

  • Page 4: Part List

    PART LIST Key No. Qty. Description Key No. Qty. Description Base M10X65mm Carriage Bolt Crossbar M10X70mm Carriage Bolt Right Lower Upright M8X20mm Bolt Left Lower Upright M10 Nut Right Upper Upright M10 Washer Left Upper Upright M8 Washer Pull-up Bar M8 Spring Washer Barbell Storage Tube Round Cap...

  • Page 5: Exploded Drawing

    EXPLODED DRAWING...
  • Page 6 ASSEMBLY Two adults assembly required. STEP 1 Identify the Base (1) and the Weight Storage Tube (9), orient them as shown. Attach one Weight Storage Tube (10) to the Base (1) with M10X70mm Carriage Bolt (17). Then, slide a Bumper (14) onto the Weight Storage Tube (9).
  • Page 7 STEP 2 Attach the Barbell Storage Tube (8) to one Base (1) as shown, secure with M10X70mm Carriage Bolt (17). 7 7 7...
  • Page 8 ASSEMBLY STEP 3 Identify the Right Lower Upright (3), Left Lower Up- right (4), and orient them as shown. Attach the Lower Upright to the Base with M10X- 65mm Carriage Bolts (16), M10 Nuts (19). Do not fully tighten the Bolts yet.
  • Page 9 STEP 4 Identify the Crossbar (2), attach the Crossbar (2) to the Base with M10X70mm Bolts (15), M10 Washers (20) and M10 Nuts (19). Do not fully tighten the Bolts yet.
  • Page 10 ASSEMBLY STEP 5 Attach the Support Plate (11) to the Lower Upright and Base with M10X70mm Bolts (15).
  • Page 11 STEP 6 Slide Support Plate (11) onto M10X70mm Bolts (15), Secure with M10 Nuts (19). Do not fully tighten the Bolts yet. 11 11...
  • Page 12 ASSEMBLY STEP 7 Put the Right Upper Upright (5) onto the Right Lower Upright, Secure with M8X20mm Bolts (18), M8 Wash- ers (21), and M8 Spring Washers (22). Repeat to attach the Left Upper Upright (6) onto the Left Lower Upright. Do not fully tighten the Bolts yet.
  • Page 13 STEP 8 Identify the Pull-up bar (7), and orient it as shown. Attach the Pull-up bar (7) to the Upper Upright with M10X70mm Bolts (15), U Plate (12) and M10 Nuts (19). Do not fully tighten the Bolts yet. 13 13...
  • Page 14 ASSEMBLY STEP 9 Put the Weight Rest (10) onto desired adjustment hole in the the Upright, secure with Plug (13). Make sure to put the Weight Rests at the same height. Tighten all the Bolts!
  • Page 15 STEP 10 Congratulations! Your Power Rack has been fully installed. 15 15...

  • Page 16: Get To Work

    GET TO WORK STEP 11 Scan the QR Code to get your FREE 30-days of programming using the GRIND App. iPhone users can simply open their camera to scan the code. How you’ll feel after 30 days Android users may need to use a scanning app. How you feel now FREE on the GRIND App*...
  • Page 17 WARNING SERIOUS INJURY OR DEATH COULD OCCUR IF THESE PRECAUTIONS ARE NOT OBSERVED » Always consult a physician before beginning any exercise program » Read and understand warning labels and user manual prior to exercise. Obtain instruction prior to use »...
  • Page 18 GRIND Fitness 30-Day Warranty PRx Performance LLC, DBA GRIND Fitness warrants to the original consumer purchaser that this product will be free of defects in material and workmanship for 30 days from the date of purchase. GRIND Fitness will repair or replace the product, at our sole option, in the event of such a defect within the warranty period.

This manual is also suitable for:

Gr130
