CWS Plus Sediment Filter Installation & Startup Guide
Fig 3: CWS Plus from the rear showing the inlet (left) and outlet (right) end-
connector fittings 1" or 1-1/4" NPT in Noryl plastic. Brass end-connectors are
also available for connecting to copper tubing.
Fig 4: CWS Plus side view
Drain Line
Page 9
Inlet
www.cleanwaterstore.com
Outlet
Bypass Knobs
(bypass position)
Inlet
Rev 120215
Outlet
