  • Page 1 Wide Body Cabinet - Cashline™ Installation Rev. 2.3 www.atronic.com May 2005...
  • Page 2 ELEASE Wide Body Cabinet (WBC) - Cashline™ Installation Rev. 2.3 Rel. May 2005 © 2000 - 2005 Atronic International GmbH. All rights reserved. May 2005...
  • Page 3 NTRODUCTION Cashline Installation Manual for Wide Body Cabinets (WBC) Atronic Technical Services is proud to introduce the WBC Cashline manual. Atronic’s Vision of “Great Games Great People” is a vision which is felt throughout the company. We hope that this manual is a strong illustration of how Atronic Technical Services is committed to making this Vision a reality.

  • Page 4: Safety Instructions

    AFETY NSTRUCTIONS Safety Instructions Follow the precautions below to en- sure safe operation. Caution! High Voltage Power cable must be disconnected from the main power socket, before the machine is free from electrical current. Main power switch is intended for service purposes only. Caution! Tipping Hazard Machine must be screwed to an appropriate base, to prevent tipping over.
  • Page 5 Danger of explosion if battery is incorrectly repla- ced! Check for correct polarity and replace with the same or equivalent type only! • Please refer to Atronic Service Manuals for further instructions on service and maintenance. Additional Information The X-rays, which develop in this machine, are suffi- ciently shielded through the Cathode-ray tube's own shielding.
  • Page 6 FOR A PARTICULAR PURPOSE, NO AFFIRMATION OF FACT, INCLUDING, BUT NOT LIMITED TO, STATEMENTS REGARDING SUITABILITY FOR USE OR PERFORMANCE OF THE PRODUCT SHALL BE DEEMED TO BE A WARRANTY OF ATRONIC FOR ANY PURPOSE. IN NO EVENT SHALL ATRONIC BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES, INCLUDING WITHOUT LIMITATION LOSS OF PROFITS, ARISING OUT OF ANY BREACH OF THIS AGREEMENT.

  • Page 7: Technical Support Telephone Numbers

    UPPORT Technical Support Telephone numbers Atronic offers and provides technical support 24 hours day, 7 days a week. If technical assistance is required during normal business hours contact your local technical services representative at one of the below numbers. If technical assistance is required outside of normal business hours, please contact one of the Atronic Technical Hotline numbers below.
  • Page 8 ACHINE OMPONENTS Machine Components Wide Body Cabinet (WBC) Toplight Latch Bar Top Box Bill Door Key Button Board Bill Door Coin Validator Monitor Bill Validator Unit Bill Head Stacker Jackpot Key Audit Key Hardmeters Door Switch Power Switch Power Supply Backplane Main Door Lock Power Board...
  • Page 9 & S OCKS WITCHES Locks, Keys and Switches Audit Key This key activates the Audit Menu and illuminates hardmeters. It also clears status and error messages. Jackpot Key Jackpot events and hand pay admin- istration are controlled by this key. It also controls remote credit func- tion (if applicable) .
  • Page 10 IMENSIONS Dimensions Cashline WBC Cabinet Weight: approx. 220 lbs. / 100 Kg (D1) see table Drawing shows WBC cabinet 18.5”/470 mm 21.7” / 550 mm with Square Top and 3 element 23.4” / 595 mm 23.9” / 606 mm candle.

  • Page 11: Technical Data

    ECHNICAL Technical Data Electrical Specifications Required Voltage: 220V-240V, 2.0A, 50Hz Primary Voltage 100V-120V, 4.0A, 60Hz Power Consumption Idle mode: approx. 185W 1.60A / 115V, 0.8A / 230V Payout mode: approx. 200W 1.75A / 115V, 0.9A / 230V Power Supply Secondary Voltage: + 24V / 4A Secondary Voltage + 12V / 4A...

  • Page 12: Machine Installation - Overview

    Hardware configuration and that Software EPROMs are correctly installed on the PCBs. Prepare the base by drilling the mounting holes. Use the Atronic drilling template for proper mounting hole placement. Place and mount the machine to the base. Run the power cable into the base. Do not connect power to the machine.

  • Page 13: Machine Installation

    Prepare bases for machine mounting Prepare base by drilling the mounting holes. Use the Atronic WBC Drilling Template for hole placement. Leave enough space between two machines. Main door should open without touching the next machine and Key Switches should be easy to access.
  • Page 14 • Connect the Toplight Molex connector (4). • Reinstall Reflector Panel and connect power cable. Replace shipping locks Atronic machines are equipped with shipping locks for easy commisioning. These locks have to be replaced by Casino specific locks to provide appropriate security.
  • Page 15 ACHINE NSTALLATION Machine Installation cont. Prepare Coin Comparitor CC16/MC16 • Slide Holder for Reference Coin rightwards, remove (plastic) transport Token and replace it with appropriate reference coin or Casino Token. • Fine tune the Coin Comparitor (if necessary) later when machine setup is completed. Quick guide for fine tuning: •...
  • Page 16 ACHINE NSTALLATION Machine Installation cont. Check DIP-Switch settings DIP switch settings are pre-set during production as specified in the order. It might be necessary to change DIP settings to meet all Casino requirements. Use the DIP switch tables within manual "Software" to check or alter DIP settings of Main board and Comm board (optional).
  • Page 17 ACHINE NSTALLATION Machine Installation cont. Configure game Configure game settings, which are accessible during normal operation. To access Service Menu open main Door and press Service Button inside the Logic Box. Service Menu has following options: • Set Clock Service Menu / Menu Setup has following options: •...
  • Page 18 ERVICE ROCEDURES Service Note: Procedures in this section should be carried out Internal Casino regulations by Trained Casino Personnel. may require different or addi- tional procedures. Warning ! Only Qualified Service Technicians should work on an open machine, if power is switched on. The machine must be switched off, if other personnel is working on the machine.
