- Page 1 Atronic e²-motion™ Installation Manual Rev. 1.2 www.atronic.com June 2008...
- Page 2 DISCLAIMER Atronic makes no representation or warranties, express or implied, with respect to this publication, or any product of Atronic, including but not limited to warranties of merchantability or fitness for any particular purpose. Atronic reserves the right to make changes, enhancements, revisions and alterations of any kind to this publication or the product(s) it covers without obligation to notify any person, institution or organization of such changes, enhancements, revisions and alterations.
-
Page 3: Table Of Contents
ONTENT Introduction About this Manual Scope, Target Audience, Included Software Releases ..Related Publications ........... Safety Instructions ............Machine Components ............Dimensions ..............Footprint / Drilling Template ......................Technical Data Machine Installation Overview ................Machine Mounting ............Topper Mounting ............... -
Page 4: Introduction
Target Audience We address qualified technical personnel, who are involved in installation, setup and configuration of Atronic gaming machines. With this user group we assume that they are basically familiar with gaming machines and casino related terminology. Please read this document and the contained safety notes carefully before you start machine installation. -
Page 5: Related Publications
Note: All mentioned manuals can be found on a CD- ROM titled "Atronic Service Manual 2008" If this manual did not came with this CD-ROM, please ask Atronic Technical Service for a free copy of the latest revision. June 2008... - Page 6 - blank page - June 2008...
-
Page 7: Safety Instructions
Caution! Tipping Hazard The machine must be fastened to an appropriate base, to prevent tipping over. Use the baseboard supplied by Atronic for machine mounting. -> see also page 17-18. Caution! Moving Parts Make sure to disconnect the hopper, when working on it. - Page 8 • Electronic assemblies should only be changed with the power switched off. • Use only original Atronic parts for replacement. • Atronic commboard and mainboard Danger of explosion if battery is incorrectly repla- ced! Check for correct polarity and replace with the same or equivalent type only! •...
- Page 9 - blank page - June 2008...
-
Page 10: Machine Components
ACHINE OMPONENTS MACHINE COMPONENTS Toplight Topper Topper Glass Toplights Topper Arch (or Blanking Cover) Framelights Top Glass Type Plate Upper Screen Voucher Printer Lower/Main Screen (optional) Service Buttons Coin Entry Player Tracking Unit (optional) Main Door Lock Loudspeakers Jackpot Key Switch Button Panel Audit Key Switch Hopper Drawer Lock... - Page 11 ACHINE OMPONENTS MACHINE COMPONENTS Top Glass Release Lever Logicbox Top Glass Lighting Logicbox Lock Logicbox Door Reset Button Service Button Filterboard Power Voucher Printer Filterboard Signal (optional) Maindoor Switch Door Motor Multimedia (MMPC) Button Panel Board Cover Release Button Coin Acceptor Power Switch Coin Optics Boards Bill Acceptor...
- Page 12 ACHINE OMPONENTS MACHINE COMPONENTS Logicbox Logicbox Switch Backplane Release Lever for Commboard Multimediaboard Cover Mainboard DVD-ROM Drive Multimediaboard Graphic Card Multimediaboard (VP11) Cover June 2008...
-
Page 13: Dimensions
IMENSIONS DIMENSIONS June 2008... -
Page 14: Footprint / Drilling Template
IMENSIONS FOOTPRINT / DRILLING TEMPLATE Backside 41.5 117.5 Baseboard Ø 10mm Ø 10mm Cabinet Footprint Make sure to leave min. 180mm (7.1") distance to the next machine or a wall on both sides of the cabinet. Do not cover the ventilation slots at both sides of the cabinet. -
Page 15: Technical Data
ECHNICAL TECHNICAL DATA Weight: approx. 114 kg (251 lbs) Required Voltage: 100V to 240V AC, 50Hz / 60Hz, use earthed power outlet rated min. 8A. Power Consumption: Idle Mode: approx. 200 Watt, 1.8A / 115V 0.9A / 230V Payout Mode: approx. 300 Watt, 2.6A / 115V 1.3A / 230V Max. - Page 16 - blank page - June 2008...
-
Page 17: Machine Installation Overview
EPROMs are correctly installed. Prepare the base by drilling the mounting holes. Use the Atronic drilling template for proper mounting hole placement. Place and mount the machine to the base, using the Universal Corpus Baseboard (see next page). -
Page 18: Machine Mounting
The machine can tip over, if it is not properly mounted to a solid base. 1. Use the baseboard, supplied by Atronic, to mark the holes on the base before drilling. Make sure to leave min. 180mm (7.1") distance to the next machine (or a wall) on both sides of the cabinet. - Page 19 ACHINE NSTALLATION MACHINE INSTALLATION Machine Mounting (continued) Caution! The machine weighs approx. 114 kg. If available, use a lift truck. Make sure that the mains power cable is completely inside the cabinet and not threaded through the lower AC hole, before sliding the machine onto the baseboard! Otherwise the cable will be damaged! 6.
-
Page 20: Topper Mounting
ACHINE NSTALLATION MACHINE INSTALLATION Topper Mounting (optional) The optional machine toppers are delivered seperately. They have to be mounted and connected. Note: Toppers with a progressive display use an addi- Hold here tional power supply not described in this manual. Please refer to the relevant mounting instructions. -
Page 21: Replace Shipping Locks
ACHINE NSTALLATION MACHINE INSTALLATION Replace shipping locks if not ordered otherwise, Atronic machines are equipped with shipping locks for easy commisioning. These locks have to be replaced by casino specific locks to provide appropriate security. Prepare Coin Acceptor (MC-16) • Slide holder for reference coin rightwards, remove (plastic) transport chip and replace it with appro- priate reference coin. -
Page 22: Check Commboard Settings
ACHINE NSTALLATION MACHINE INSTALLATION Commboard Check Commboard Settings The commboard DIP switches and rotary switches Logicbox configure SAS address, APL address, progressive Cover mode and SAS (dual) channel allocation. Use the DIP switch tables within manual "Software / Basic Setup" for a particular software version (e.g. C5.1.x) to check or alter the commboard settings. -
Page 23: Basic Setup (Overview Only)
Initial Setup menu. The Initial Setup al- lows to configure all basic machine setting. 4. Carry out Progressive Jackpot Configuration A PC or notebook with Atronic's Alink Config soft- ware is connected to the gaming machine and uploads the progressive jackpot configuration data. -
Page 24: Tests
ESTS TESTS Test Bill and Coin Handling Open maindoor and press the Service button at front of the logic box. The Service Menu is displayed. Select file tab Diagnostics. • Test coin handling. -> / Coin Acceptor / Optics Test •... -
Page 25: Technical Support Telephone Numbers
UPPORT TECHNICAL SUPPORT TELEPHONE NUMBERS Atronic offers and provides technical support 24 hours a day, 7 days a week. If technical assistance is required during normal business hours, please contact your local technical services representative at one of the numbers below.
