  • Page 1 Atronic e-motion™ Installation Manual Rev. 2.2 www.atronic.com June 2008...
  • Page 2 The e-motion™ / Hi(!)bility™ manual is intended to provide QUALIFIED TECHNICAL PERSONNEL ONL Y with the information necessary to routinely maintain, service, and repair the Atronic e-motion cabinet and components. To avoid personal injury or damage to the equipment, do not perform any serviceing other than that contained in this manual.

  • Page 3: Table Of Contents

    ONTENT Introduction About this Manual Scope, Target Audience, Included Software Releases ..Related Publications ........... Safety Instructions ............Machine Components ............Dimensions ..............Technical Data ..............Machine Installation Overview ................Machine Mounting ............Drilling Template ............... Replace Shipping Locks ............. Prepare Coin Acceptor ............

  • Page 4: Introduction

    Target Audience We address qualified technical personnel, who are involved in installation, setup and configuration of Atronic gaming machines. With this user group we assume that they are basically familiar with gaming machines and casino related terminology. Please read this document and the contained safety notes carefully before you start machine installation.

  • Page 5: Related Publications

    Note: All mentioned manuals can be found on a CD- ROM titled "Atronic Service Manual 2008" If this manual did not came with this CD-ROM, please ask Atronic Technical Service for a free copy of the latest revision. April 2008...
  • Page 6 - blank page - April 2008...

  • Page 7: Safety Instructions

    Note! This installation module of the e-motion™ Hi(!)bility includes only information relating to the installation of the e-motion™ cabinet. For other machine or cabinet types please refer to the relevant manuals. Follow the safety precautions below and on the next page, to ensure safe operation.
  • Page 8 • Electronic assemblies should only be changed with the power switched off. • Use only original Atronic parts for replacement. • Atronic commboard and mainboard Danger of explosion if battery is incorrectly repla- ced! Check for correct polarity and replace with the same or equivalent type only! •...
  • Page 9 - blank page - April 2008...

  • Page 10: Machine Components

    Playfield Height Adjustment Mechanical Meters Button Panel Main Door Lock Jackpot Key Switch Audit Key Switch Hopper Drawer Hopper Drawer Lock Coin Bowl Bill Entry / Bill Acceptor Bill Decal Name Plate Atronic Installation Station (AIS) (Baseplate for mounting) April 2008...
  • Page 11 ACHINE OMPONENTS MACHINE COMPONENTS Logicbox Top Glass Filterboard Filterboard Logic Door Release Lever Power Signal Logic Door Lock Reset Button Service Button Multimedia Board Cover Maindoor Switch Coin Unit Assembly Coin Acceptor Coin Optics Bill Acceptor Front Bezel Decal Lighting Bill Acceptor Door Motor Button Panel...
  • Page 12 ACHINE OMPONENTS MACHINE COMPONENTS Logic Box Logicbox Switch Backplane Release Lever for Commboard Multimediaboard Cover Mainboard DVD-ROM Drive Multimediaboard Graphic Card Multimediaboard (VP11) Cover April 2008...

  • Page 13: Dimensions

    IMENSIONS DIMENSIONS e-motion™ Cabinet 575 - 590 Weight: approx. 120 Kg / 264 lbs. Overall dimensions closed cabinet Height: max. 1350 mm / 53.2" Width: 610 mm / 24" Depth: max. 590 mm / 23.2" (575 opened closed 685 (mm) e-motion™...

  • Page 14: Technical Data

    ECHNICAL TECHNICAL DATA Electrical Specifications Primary Voltage Required Voltage: 100V to 240V AC (The power supply features 50Hz / 60Hz voltage autoswitching) The mains power cable must be pluged into a earthed power outlet labled 8 Amps. Power Consumption Idle Mode: approx.
  • Page 15 - blank page - April 2008...

  • Page 16: Machine Installation Overview

    Check that all EPROMs are correctly seated on the boards. Prepare the machine bases by drilling the mounting holes. Use the Atronic drilling template for proper mounting hole placement. Place and mount the machine to the base, using the Atronic Installation Station (AIS).

  • Page 17: Machine Mounting

    1. Use the Atronic Installation Station (AIS), supplied by Atronic, to mark the holes on the base before drilling. Make sure to leave min. 180mm (7.1") distance to the next machine or a wall on both sides of the cabinet.

  • Page 18: Drilling Template

    ACHINE NSTALLATION DRILLING TEMPLATE 270.5 105.5 Backside Ø 10mm (drill 1 out of 3 for securing bolt) Ø 10mm Baseplate (AIS) Cabinet Footprint Make sure to leave min. 180mm (7.1") distance to the next machine or a wall on both sides of the cabinet. Do not cover the ventilation slots at the backside of the cabinet.

  • Page 19: Replace Shipping Locks

    Replace Shipping Locks If not ordered otherwise, Atronic machines are equipped with shipping locks for easy commisioning. These locks have to be replaced by casino specific locks to provide appropriate security.

  • Page 20: Prepare Coin Acceptor

    ACHINE NSTALLATION MACHINE INSTALLATION continued Prepare Coin Acceptor (CC-16 / MC-16) • Slide holder for reference coin rightwards, remove (plastic) transport chip and replace it with appro- priate reference coin. • Check reference coin for proper (parallel) seating. -> See manuals Peripherals / Coin Acceptor for details. Prepare Hopper The hopper high level switch detects the filling level of the hopper by the weight of the coins.

  • Page 21: Apply Power

    ACHINE NSTALLATION MACHINE INSTALLATION continued Apply Power • Punch out one of the perforated knock-out plates in order to provide access for the power cable (fi- gure a). • Mount the enclosed edge protection (figure b). • Check that the machine mains cable has not been damaged during transit.

  • Page 22: Basic Setup (Overview Only)

    Initial Setup menu. The Initial Setup al- lows to configure all basic machine setting. 4.Carry out (Progressive) Jackpot Configuration A PC or notebook with Atronic's Alink Config soft- ware is connected to the gaming machine and uploads the progressive jackpot configuration data.

  • Page 23: Tests

    ESTS TESTS Test Bill and Coin Handling In order to access the Diagnostics menu open maindoor and press the service button at front of the logic box. The Service Menu is displayed. Select file tab "Diagnostics". • Check coin channeling optics. ->...

  • Page 24: Technical Support Telephone Numbers

    UPPORT TECHNICAL SUPPORT TELEPHONE NUMBERS Atronic offers and provides technical support 24 hours a day, 7 days a week. If technical assistance is required during normal business hours, please contact your local technical services representative at one of the numbers below.
