- Page 1 Yagi Dipole Vertical (Patent# 6,677,914 2E - 3E High Wind Kit Manual Antarctica at 75 mph SteppIR Antennas 2112 -116th Ave NE, Suite 2-5 , Bellevue, WA 98004 Tel: 425-453-1910 Fax: 425-462-4415 Tech Support: 425-891-6134 Rev: NEW 11-08-07 www.steppir.com...
- Page 2 Table of Contents TOPIC Page Table of Contents SteppIR Why Compromise? Parts List 5 - 6 Drawings - Boom to Mast Plate 7-11 Assembly Instructions...
-
Page 3: Steppir - Why Compromise
SteppIR to be a commercially feasible product. The current and future SteppIR products should produce the most potent single tower antenna systems ever seen in Amateur Radio! We thank you for using our SteppIR antenna for your Warm Regards,... - Page 4 SteppIR Antennas — 2E - 3E High Wind Kit PART DESCRIPTION ITEM MAST PLATE ASSEMBLY 10-1021-xx 8” x 8” MAST PLATE IN BOX x MAST HARDWARE 60-0066 5/16-18 x 4” SS BOLT BAG 1 60-0046 5/16-18 SS NYLOK NUT 60-0042 REINFORCEMENT STRAP 10-16xx-01 2"...
- Page 5 SteppIR Antennas — 2E - 3E High Wind Kit 8 " Ø 1 . 2 Ø Ø 4 "...
- Page 6 SteppIR Antennas — 2E - 3E High Wind Kit 1 . 7 Ø 1 . 3 Ø 1 . 2 Ø Ø...
- Page 7 SteppIR Antennas — 2E - 3E High Wind Kit The high wind kit for the 2 and 3 element Yagis will consist of additional hardware to provide a stronger and more secure mounting in environments where severe winds may be a problem.
- Page 8 SteppIR Antennas — 2E - 3E High Wind Kit Picture 3/8-16 x 4 SS Full Thread 2” Mast Bolt W/Split Washer Saddles If you are going to mount the mast plate to a temporary mast then continue your antenna assembly: Put the mast plate assembly against the mast Assemble a reinforcing strap with two 5/16-18 x 4”...
- Page 9 SteppIR Antennas — 2E - 3E High Wind Kit Boom Installation for 2 Element (20m - 6m): Measure the overall length of the boom and mark the midpoint Boom Installation for 2 Element (W/40m-30m Dipole): Temporarily mount the boom as shown in the 40m-30m Dipole manual choosing your...
- Page 10 SteppIR Antennas — 2E - 3E High Wind Kit Picture EZ-Eye Stud EZ-Eye Bolt 2E - Boom 2 in Mid Point of 2E - Boom Mast Picture EZ-Eye Stud EZ-Eye Bolt Two washers on each side of the eye...
- Page 11 SteppIR Antennas — 2E - 3E High Wind Kit Boom Installation for 3 Element: Remove the vertical 1/4-20 bolt from the #2 splice Drill out the hole with the included “N” (.320”) drill bit Install the 5/16-18 eye bolt with the eye parallel to the boom (Picture 17 )
- Page 12 SteppIR Antennas — 2E - 3E High Wind Kit www.steppir.com L i m i t e d W a r r a n t y These products have a limited warranty against manufacturer’s defects in materials or construction for two (2) years from date of sale.
- Page 13 40m - 30m Dipole Option www.steppir.com Yagi Dipole Vertical...
