Summary of Contents for CAS HDI
-
Page 2: Table Of Contents
CONTENTS PRECAUTIONS ..........4 PREFACE ............6 INSTALLATION & CONNECTION ... 6 CALIBRATION ..........7 OPERATIONS ..........9 ........10 1. General Weighing ........10 2. Weighing with Tare ........... 11 3. Counting Mode . 12 4. Weight Comparison Function(HI/OK/LOW) .......... -
Page 3: Precautions
PRECAUTIONS... -
Page 5: Preface
PREFACE Thank you for the purchasing of CAS HDI Indicator. This Indicator has been designed with CAS reliability, under rigid quality control and with outstanding performance. Your specialty departments can enjoy with CAS products. We hope that CAS product meets your needs. -
Page 6: Calibration
CALIBRATION Product initialization Press key to go to Power on When numbers on the display appears press CAL S/W. There will be a beeping sound as the product initializes. - General Calibration * If the product initiation process is skipped, the #4 value will automatically be set to the previously set value and the setup process will be skipped. - Page 7 Calibration mode Zero Calibration (Check that the scale reads zero) Span Calibration Input value. Note: Input values in Kg. Place the previously inputted amount of weight on the scale and then press Select Calibration complete...
-
Page 8: Operations
OPERATIONS DISPLAY AND KEYBOARD KEY FUNCTIONS KEYS DESCRIPTIONS Used to set the zero point to 0.00. Used as an ESC key in Setup Mode. Used to enter a tare weight and used to cancel a tare weight. Used to convert the mode as below. [kg] ... -
Page 9: General Weighing
1. General Weighing ■ The display indicates if the scale is at zero or if there is a tare entered into the scale by way of a ZERO and NET. ① Turn on the power. ② ③ Place an item on the platter. When the display is not zero The display shows 0.00. -
Page 10: Counting Mode
3. Counting Mode ■ Samples on the platter. ① Press the MODE key until ② Press the SAMPLE key, ③ If you want to increase the display shows “WL OFF”. then the display shows “10”. sample size, press the If you have set sample size SAMPLE key. -
Page 11: Weight Comparison Function(Hi/Ok/Low)
4. Weight Comparison Function(HI/OK/LOW) ① Press the MODE key until ② Press the SAMPLE key to ③ Press the SET key to set up the display shows “WL OFF”. activate this function, the low value, the display shows It means that weight limit display shows “WL ON”. - Page 12 ⑩ Suppose that the High limit of 70kg and the Low limit of 30kg are set up. In this condition, lamp is lighted on if the weight is 40kg, lamp is lighted on if the weight is 80kg and if the weight is 20kg, lamp is lighted on.
-
Page 13: Print Out
5. Print Out 5-1. Manual Print ■ You can print out data every time pressing the PRINT key. You can setup print function depends on your need. Refer to User Mode Table on page 17. 5-2. Auto Print ① To use auto print function, you have to set printer method = 1 in User mode. Refer to User Mode Table on page 17. -
Page 14: Battery Charge
6. Battery Charge ■ Warning massage is shown when the battery voltage is very low. ( ■ At this time, charge the battery. ■ The display will show a red lamp and the battery will begin a fast charge automatically. - Use only the ac adapter which comes with the scale. -
Page 15: User Mode
User Mode Pressing and holding key press key to go to user mode. (a) (b) (c) (d) (e) (f) (a) Backlight: 1 – Auto , 2 – On , 3 - Off (b) Auto Power Off : 0 - off , 1 – 10min , 2- 30min , 3- 60min (c) Unit of measure : 0 –... -
Page 16: Error Messages
Description Solution on Display The "Z-Err" occurs when a current zero point “Z-Err” Please call your CAS dealer. has shifted from the last span calibration. “ oL” The "oL" is an overload error. Please remove the weight. “b - Err”... -
Page 17: Specifications
SPECIFICATIONS Load Cell Excitation DC 5 V Voltage Zero Adjustment 0.05 mV ~ 5 mV Range Input Sensitivity 2 uV/D 1/300000 Internal Resolution 1/30000 External Resolution Division X1, x2, x5, x10 , x20 , x50 10 Hz Conversion Speed Display Below Zero Minus DISPLAY LCD 6 digits 110mm(W) X 35mm(H) - Page 18 MEMO...
