Surveon CAM2 Series Quick Installation Manual

Box Network Camera
QUICK INSTALLATION GUIDE

Hardware Installation

Warning!
1 Rear View and Installation
Only qualified service personnel should install
and service this product in order to avoid risk
of injury from electrical shock and energy
( DC IRIS
hazards.
Certain models only)
Caution!
Observe all ESD (Electro-static Discharge)
procedures during installation to avoid damage
to the system and other components.
Tools required
1.
Fasten screws to secure
camera stand to the ceiling or
a flat surface.
Anti-static
Phillips
Wrist Strap
Screwdriver
2.
Loosen the lock ring to adjust the
Accessories desired angle of the camera.
Retighten the lock ring after desired
angle is achieved.
1x Product DVD
●
3x Mounting Screws
●
1x Camera Stand
●
1x Quick Installation Guide
●
1x RoHs compliance
●
1x Hexagonal wrench
●
NOTE:
CS-ring
●
Cameras are for
1x 12V 1.5A Power Adapter (Optional)
indoor use only.
●
Lens (Option)
●
Power Requirements
Using the included power adapter:
Input: 100-240 VAC 50/60Hz 0.4A
Output: 12VDC, 1.5A
2 Front View & LED Definitions
* A DC IRIS-equipped camera is shown below.
DC IRIS Cable( Certain models only)
LED
Zoom & Focus Adjust. Bars
LED
Off
Static Green
Flashing Green
Steady Amber
Flashing Amber - ON: 0.2 sec, OFF: 0.2 sec
Flashing Amber - ON: 0.2 sec, OFF: 0.5 sec
microphone
* Note: CAM23xx doesn't have LED and Microphone
3

Camera Deployment

PTZ controller
DC IRIS*
FTP
NAS Email server
DC-IRIS
Router
microSDHC 2 microSDHC
POWER RESET
Internet
* Supports boot
from SD
on SDHC1
Router
MicroSD
Amplifier-enabled
Microphone
* Certain models only
Client Client
Q M0 C A M2 E 2 R 1 2
© by Surveon Technology, Inc. All rights reserved.
3

Software Installation

2
1

Network Configuration

1. Use the default IP to access the camera: 192.168.88.10 or
2. Using the device utility in your product CD, which discovers cameras, DVRs, or NVRs within the same
level2 or level3 network, locate or set up a static IP for your camera
DC-IRIS
DC12V
AUDIO IN AUDIO OUT
microSDHC 2 microSDHC 1
POWER RESET
Note :
The camera will attempt to obtain an IP via DHCP, but will use the default IP if DHCP service is
not found. To re-enable DHCP IP assignment, reset the camera.
3. With a valid IP, access the camera's web-based configuration utility by opening an IE browser.
Key in http://<IP address> on the URL field.
Definitions
Power Off
Status Normal
Video traffic
Initial startup
Restored to factory defaults
Restoring defaults; Upgrading firmware;
Upgrade failure
Key in the default user name and password to login.
The defaults are: admin / admin
* admin
User Name:
admin
Password:
Sensor *
Alarm *
DC12V
AUDIO IN AUDIO OUT
1
To Reset:
Press and hold the button down
for 3 seconds when powering on
to restore factory defaults.
In addition to power adapter,
PoE (802.11AF compliant) is
also supported.
Speaker
You will be prompted
to change your password
172. 16 80 .
255. 255 255
172.16.80.1
172.16.80.100
119.6 . 6 .6
http://172.16.80.4/index.cgi
MPEG4
QVGA(320x240)
SXGA(1280x1024)
Once successfully logged in, live video displays in the center of your
browser.
H.264 Surveon CAM3260
VGA(640x480)

Configure Admin Password

admin
User Name:
Old Password:
New Password:
Confirm Password:
When entering the Live section View of the camera's web-based interface, you will be prompted to install
ActiveX control components. Click on the message prompt to install. If IE blocks the installation, you will
need to open the following options to continue with installation:
On your IE browser, access Tools -> Internet Options -> Security -> Custom Levels. Enable "Download
Signed ActiveX controls" and click ok to save this setting.
Security level for this zone
Custom Level
.188
. .0
When ActiveX control components are installed, access Tools -> Internet Options ->Security ->
Trusted Sites ->Sites on your browser. Enter the IP configured for the camera and click OK
to complete the process.
Trusted sites
2010 03 01 01:53:40
For details about accessing camera video using QuickTime or Realplayer over RTSP and
3GPP, please refer to your user guide. The user guide is provided in your product DVD.
Default Level
http://172.16.80.4
http://effice.infortrend.com
Trusted Megapixel IP Video Solutions
