Page 1: User Manual
CAM4310 Megapixel IR Dome Indoor Network Camera User Manual Release 1.0 December, 2010... -
Page 3: Copyright Statement
Product specifications are also subject to change without notice. Trademarks Surveon and Surveon logo are trademarks of Surveon Technology Inc. All other names, brands, products or services are trademarks or registered trademarks of their respective owners... -
Page 4: Table Of Contents
Control Descriptions ..............15 3.2. Settings ................17 General..................17 Basic Settings ............... 17 User Account ................ 19 Date & Time ................. 22 Network ................... 23 Network Configuration............. 24 Port Settings................. 25 UPnP .................. 26 Video & Audio Settings ..............27 www.surveon.com... - Page 5 DI & DO................44 Event Settings ............... 46 System..................52 MicroSD Card Management............52 System Status ............... 53 System log ................54 Firmware Upgrade..............55 Reset to Factory Default ............56 Export/Import & Reboot ............57 Surveon Network Camera User Manual...
-
Page 6: Chapter 1. Overview
Chapter 1. Overview 1.1. Network Camera Introduction CAM4310 is a professional IP network camera utilizing Internet Protocol (IP) to transmit video streams and control signals over networks. Capable of operating over both LANs and WANs, CAM4310 provides a complete budget-conscious remote surveillance solution that is ultra clear and highly integrated. -
Page 7: Network Camera Specifications
Motion detection, tampering detection Intelligent (blocked, redirected, defocused, video or spray-painted) Built-in MIC Omni-directional Audio 32KHz, ADPCM compression Audio input 3.5mm phone jack Audio output 3.5mm phone jack Alarm in 2, terminal block Alarm out 1, terminal block Surveon Network Camera User Manual... - Page 8 Ethernet 10/100 Base-T / RJ45 Local storage microSD/SDHC card slot x 1 (Class 4/Class 6 only) RS-485 1 (2 pins on terminal block) Surveon SDK 2.0 Microsoft Windows XP/Vista/7 Browser Microsoft IE 6.0 or above Software Surveon VMS 2.0 Operation: -10 ~ 50 ℃ (14 ~ 122℉) Temperature Storage: -30 ~ 70 ℃(-22 ~ 158℉)
-
Page 9: System Structure
Connect the camera to a power source. CAM4310s can accept power from a power adapter or from Power over Ethernet enabled switches. Connect the camera to a switch using an Ethernet cable. The Ethernet port is located on the rear of the camera. Surveon Network Camera User Manual... -
Page 10: Chapter 2. Connecting To The Network Camera
This section demonstrates how to connect to the network camera through two methods: • Web Browser – A simple web-based interface. Internet Explorer is the recommended web browser for use with Surveon network cameras, and our examples will be from this browser. Usage on other browsers will be similar. •... -
Page 11: Connecting With A Web Browser
Enter the IP address of the network camera in the address bar of your browser and press enter. The IP address can be obtained using the Surveon IP Utility, or if your network does not have DHCP service, the default IP address is 192.168.88.10. -
Page 12: Logging Into The System For The First Time
In the New password and Confirm new password field, fill in the new password. Click OK to change the password. If at any time you lose this password, performing a hard reset of the camera will restore the password back to admin. www.surveon.com... -
Page 13: Installing Active X Components In Internet Explorer
Search for Download signed ActiveX controls. Under this heading select Prompt and then click OK. Continue installing the Active X components. After installing ActiveX, go to Tools> Internet Options> Trusted Websites> Sites and add the IP Address of the camera. Surveon Network Camera User Manual... -
Page 14: Logging Out Of The System
This provides simple explanation of the camera settings, and will automatically open to the page relevant to your current screen. The help manual is organized so that it matches the system menus, with sections corresponding to each settings menu and the Live-view window. www.surveon.com... -
Page 15: Connecting With An Rtsp Player
CAM4310 2.2. Connecting with an RTSP Player Surveon cameras support connections through RTSP Media Players such as Real Player and QuickTime Player. Launch Real Player or QuickTime Player； Select File> Open URL, to open a URL dialog box. Enter the camera URL in the address bar. -
Page 16: Chapter 3. Web Interface
4. Live View Window - This portion of the screen displays the stream selected in the Live View Control section of the web interface. www.surveon.com... -
Page 17: Control Descriptions
Full-Screen: Goes to full-screen when clicked; press “ESC” to return to windowed view. Image Capture: When clicked, captures the current screen as an image in a new pop-up window and saves it in C:\Surveon\Record. This location can be changed under Settings> Recording> Recording Basic Settings. file name “Camera... - Page 18 (320 x 240), QQVGA (160 x 120) for stream 2. Digital Zoom: When clicked, activates digital zoom in the current live-view stream. 2 options are available when clicked: Zoom In Zoom Out Digital Output: Sets the Digital Output to High, Low, or Off. Default is Off. www.surveon.com...
-
Page 19: Settings
":" character. • Camera Name: by default set to "Surveon + model name"; after selecting Camera Name” from Settings> Video & Audio> Basic Settings, the Camera Name will show on the display. Users may replace the default name with a new name consisting of alphanumeric characters, spaces and the ":"... - Page 20 LED off during camera access - LED default on, off during camera access o LED always off - LED always off Click OK to save or Cancel to abort the changes before you leave the page. www.surveon.com...
-
Page 21: User Account
1 to 10 in this field to limit the number of users that can view the live view stream for this camera. This option will only be displayed once you add an account. Click OK to save or Cancel to abort the changes before you leave the page. Surveon Network Camera User Manual... - Page 22 • Password - a passkey used to control user access. This password should be retyped in the Confirm password field, to ensure that the correct key is saved. Click OK when finished to add the user to the system. www.surveon.com...
- Page 23 In General> User Account under the User Account heading, select an existing account by clicking on the account entry. The entry will be highlighted in yellow. Click Remove and, when prompted to confirm deletion, click OK to remove the account. Surveon Network Camera User Manual...
-
Page 24: Date & Time
Manual update - Updates the time manually. Choose the appropriate date and enter a time for the system. • Synchronize with computer time - Synchronizes the time with the computer’s internal clock. Click OK to save or Cancel to abort the changes before you leave the page. www.surveon.com... -
Page 25: Network
CAM4310 Network The network settings, including network configuration, port configuration, and universal plug and play (UPnP) settings are used to configure camera connectivity. These settings are found under the Settings > Network context. Surveon Network Camera User Manual... -
Page 26: Network Configuration
Select desired DDNS service website, check the Enable DDNS option, and fill in valid user name and password. You can then access the camera through the registered domain name. Click OK to save or Cancel to abort the changes before you leave the page. www.surveon.com... -
Page 27: Port Settings
The RTP port number must be an even number. After entering the Note: RTP port number, the RTCP port number will automatically be set to the RTP port number + 1. Click OK to save or Cancel to abort the changes before you leave the page. Surveon Network Camera User Manual... -
Page 28: Upnp
If the computer does not have UPnP installed, you can add it by going Note: to Start> Control Panel> Add or Remove Programs. In the Add or Remove Programs page, select Add/Remove Windows Components>Networking Services and click Details. Select UPnP from the popup window, and OK out to install UPnP services. www.surveon.com... -
Page 29: Video & Audio Settings
Camera Name - Displays the name of the camera. Audio Settings Select the desired button to turn audio from the camera on or off. Click OK to save or Cancel to abort the changes before you leave the page. Surveon Network Camera User Manual... -
Page 30: Image Appearance
CAM2200/2400 Image Appearance These settings, found under Video & Audio> Image Appearance, deal with the video output of the CAM4310. There are two tabs, Image Attributes and Sensor Configuration, as well as Advanced Settings. Image Attributes These parameters deal with the image lighting and color. All parameters are values ranging from (0) to (100). - Page 31 Setting this parameter to high will result in a high backlighting (making the foreground more visible) while setting this parameter to low will make objects in the backlit area more visible. The Middle setting sets the backlit to a medium amount. Surveon Network Camera User Manual...
- Page 32 Frame Rate First – The camera will raise the gain rate to preserve the shutter speed specified in the Shutter Speed dropdown. o Shutter Priority First – The camera will use a shutter speed which is at least as fast as the shutter specified. www.surveon.com...
- Page 33 To: - The time, in hours and minutes, when the camera will switch to night mode. Click OK to save or Cancel to abort the changes before you leave the page. Surveon Network Camera User Manual...
-
Page 34: Video Streams
Stream 1 only), HD720 (1280 x 720, Stream 1 only), VGA(640x480), QVGA(320x240) , QQVGA(160x120, Stream 2 and MPEG4 only). • Video Frames per Second - Sets the number of frames per second. 1, 3, 5, 10, 15, 20, 25, 30 FPS are possible values. www.surveon.com... - Page 35 QQVGA video, with MPEG4 compression at 128kbps and 10 seconds between key frames. None of the parameters can be changed. Click OK to save or Cancel to abort the changes before you leave the page. Surveon Network Camera User Manual...
-
Page 36: Audio Settings
Only one bit rate, 32 Kbps, is currently supported. Audio will be encoded at this bit rate. Click OK to save or Cancel to abort the changes before you leave the page. Only Stream 1 supports audio. Note: www.surveon.com... -
Page 37: Ptz
PTZ protocol - The protocol used by the PTZ. Two of the most common protocols are supported: Pelco-D and Pelco-P. Click OK to save or Cancel to abort the changes before you leave the page. Surveon Network Camera User Manual... -
Page 38: Recording
Event/Schedule Record To: - Allows the user to set the destination for event or scheduled recording. Event and scheduled recording settings are found under Settings> Event Notification. Click OK to save or Cancel to abort the changes before you leave the page. www.surveon.com... -
Page 39: Recorded File Management
You may also narrow the entries displayed by clicking on the Media Type column. This will give you the option of choosing All, H264, MPEG4, or MJPEG types. The system will only show video files of the format selected. Surveon Network Camera User Manual... - Page 40 You can also record live video by clicking the record button in the Live View screen, which will be stored directly into your local computer, and are not managed by this function. Please refer to the section on Manual Record for more information on this functionality. www.surveon.com...
-
Page 41: Event Notification
SMTP Server Port - the SMTP port of the email server; Default 25. • Test - Click this button to send a test email. E-mails will only be sent if all parameters are entered correctly. Surveon Network Camera User Manual... - Page 42 User Name - The user name of the NAS account. • Password - The password of the NAS account. • Folder Name - The name of the CIFS account folder on the server. Click OK to save or Cancel to abort the changes before you leave the page. www.surveon.com...
-
Page 43: Motion Detection
To delete a window, select a window in and click Remove. After windows are set, you can activate motion detection by checking the Enable Motion Detection box. Surveon Network Camera User Manual... - Page 44 When the motion value reaches or crosses the Trigger Threshold, denoted by the red line, a motion event will be triggered. Motion alarm handling and notifications can be configured under Event Settings. www.surveon.com...
-
Page 45: Tampering Detection
Options are Very Low, Low, Normal, High, and Very High. Higher sensitivities can detect more tampering attempts, but also increase the chances that the camera will produce a false alarm. Click OK to save or Cancel to abort the changes before you leave the page. Surveon Network Camera User Manual... -
Page 46: Di & Do
Normal Close – the DI requires a high voltage input (+12V), with the following configuration. It is triggered when it does not receive this input. • Off - DI inputs are closed at all times. The camera will not respond to any signals on this DI. www.surveon.com... - Page 47 Low - DO acts as a ground when triggered, and is connected to the output circuit in the following manner: • Off - Closes DO output; no signals will be sent. Click OK to save or Cancel to abort the changes before you leave the page. Surveon Network Camera User Manual...
-
Page 48: Event Settings
Select – Clicking on an existing rule selects the rule, highlighting it in yellow. o Edit – A selected rule may be edited by clicking on the Edit button. o Delete – A selected rule may be deleted by clicking on the Delete button. www.surveon.com... - Page 49 If editing a rule that has not been triggered, the rule will not be Note: triggered after until after editing is complete. If the rule is triggered, any changes will not be applied until the current trigger is resolved. Surveon Network Camera User Manual...
- Page 50 Detection for more detail. • Disk Full - Trigger when the SD disk installed in the camera is full. • DI - Trigger when a DI trigger occurs. For more information please refer to the section on DI & www.surveon.com...
- Page 51 Options are 1, 2, 5, 10, 20 or 30 seconds. For more information please refer to the section on DI & Click OK to save or Cancel to abort the changes before you leave the page. Surveon Network Camera User Manual...
- Page 52 From: and To: boxes. • Never – The event is never triggered. www.surveon.com...
- Page 53 Options are 1, 2, 5, 10, 20 or 30 seconds. For more information please refer to the section on DI & Click OK to save or Cancel to abort the changes before you leave the page. Surveon Network Camera User Manual...
-
Page 54: System
Settings> System. MicroSD Card Management Surveon cameras can all access MicroSD class 4/6 cards for offline video storage and upgrade purposes. MicroSD installed in the camera can be managed under System> MicroSD Card Management. -
Page 55: System Status
Camera System Information o Boot Loader Version o Firmware Version Clicking on the Email button will send the system status information out to the notification e-mail address specified in Event Server for troubleshooting or reference purposes. Surveon Network Camera User Manual... -
Page 56: System Log
This information can be very useful in the event of a camera failure or unauthorized entry. Clicking Email will send the log out as an email the notification e-mail address specified in Event Server; Clicking Download will begin the browser download process to download the log to the local PC. www.surveon.com... -
Page 57: Firmware Upgrade
In certain cases, improvements to the camera firmware will be made to improve the image quality or enhance the usability of the camera. These upgrades will be made available via Surveon support or our website www.surveon.com. Once you have obtained a new firmware file, firmware upgrades can be performed under System>... -
Page 58: Reset To Factory Default
(no configurations retained). To reset the camera by pressing the “Reset” button on the bottom of the camera, press and hold the “Reset” button for 3 seconds. During this time, the LED indicator in front of the camera will blink in red. www.surveon.com... -
Page 59: Export/Import & Reboot
Import Configuration - Imports previously exported camera settings. The field should contain the path for the camera configuration file. Click Browse: to browse your PC for the configuration file. Click Apply to import the settings. Surveon Network Camera User Manual...
