Surveon CAM2441HC-5 User Manual

H.265 network cameras

Advertisement

Quick Links

H.265 Network Cameras
User Manual
Ver. 1.0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAM2441HC-5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Surveon CAM2441HC-5

  • Page 1 H.265 Network Cameras User Manual Ver. 1.0...
  • Page 2: All Rights Reserved © Surveon Technology 2019

    Furthermore, Surveon Technology reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation to notify any person of such revisions or changes.
  • Page 3: Revision History

    Revision History Version Description Date Initial release October 2019...
  • Page 4: Disclaimer

    Disclaimer CAUTION! The default password is used for your first login. To ensure account security, please change the password after your first login. You are recommended to set a strong password (no less than eight characters). To the maximum extent permitted by applicable law, the product described, with its hardware, ...
  • Page 5: Table Of Contents

    All Rights Reserved © Surveon Technology 2019 · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·...
  • Page 6: Chapter 1. Overview

    Chapter 1. Overview CAM2441HC-5 H.265 Box IP Camera is capable of simultaneous video streaming in H.265, H.264 and M-JPEG format. The camera has a maximum resolution of 4MP @ 30fps in both H.265 and H.264 in High Dynamic Range (HDR) mode to ensure more image details are captured under challenging lighting conditions.
  • Page 7: Package Contents

    1.2 Package Contents Please check the package containing the following items listed below. CAM2441HC-5 H.265 Box IP Camera 2-Pin Power Terminal Block Quick Guide NOTE: To use an external power supply, please contact the camera manufacturer to confirm that the power supply uses the same power specifications as the camera. The power supply must comply with the LPS requirements.
  • Page 8: Dimensions

    1.3 Dimensions The dimensions of the camera are shown below. Non-ABF Models ABF Models...
  • Page 9: Connectors

    1.4 Connectors The diagram below shows the various connectors of the camera. Definition for each connector is given as follows. Connector Definition Remarks For analogue video output Network LEDs For network activity and power connection indication Auto Iris Auto iris lens connection Audio (Line Two-way audio transmission...
  • Page 10: Light Sensor

    NOTE: It is not recommended to record with the microSD card for 24/7 continuously, as it may not be able to support long term continuous data read/write. Please contact the manufacturer of the microSD card for information regarding the reliability and life expectancy. 1.4.1 Light Sensor A light sensor is used to detect the ambient light for day/night switching function.
  • Page 11: Chapter 2. Camera Cabling

    Chapter 2. Camera Cabling Please follow the instructions below to complete the cable connections. NOTE: This camera must be installed by qualified personnel and the installation should conform to all local codes. 2.1 Power Connection For power connection, please refer to section Connectors. Alternatively, users can power the camera by PoE if a Power Sourcing Equipment (PSE) switch is available.
  • Page 12: Lens Mounting

    2.3 Lens Mounting Follow the steps below to mount the C/CS Mount Lens to the camera. Step 1: Remove the plastic cover of the camera. Step 2: Remove the dustproof protective film from the CMOS image sensor. Step 3: For Non-ABF models, mount the C/CS Mount Adapter to the camera. Step 4: Attach the C/CS Mount Lens to the adapter.
  • Page 13: Chapter 3. System Requirements

    Chapter 3. System Requirements To perform the IP camera via web browser, please ensure the PC is in good network connection, and meet system requirements as described below. Items System Requirement Minimum : 1. Intel® CoreTM i5-2430M @ 2.4 GHz 2.
  • Page 14: Chapter 4. Access Camera

    Chapter 4. Access Camera For initial access to the IP camera, users can search the camera through the installer program: Search Tool.exe. Accessing the Camera by Device Search Software Step 1: Double click on the program Device Search.exe. Step 2:After its window appears, click on the <Device Search> button on the top. All the finding IP devices will be listed in the page.
  • Page 15 Step 8: A prompt window requesting for default username and password will appear. Enter the default username and password shown below to login to the camera. Login ID Password Admin 1234 NOTE: ID and password are case sensitive. NOTE: It is strongly recommended that administrator’s password be altered for the security concerns.
  • Page 16 Once the Viewer is successfully installed, the Home page of the IP camera will be able to correctly display as the figure below. Non-ABF Models...
  • Page 17 ABF Models...
  • Page 18 4.1 Lock ABF Function (ABF Models Only) Lock function is to lock the ABF function of the camera after focus is adjusted to the best position. This function is to prevent the camera from being out of focus when the camera is moved afterwards or is accidentally adjusted locally or remotely via NVR/VMS.
  • Page 19: Chapter 5. Setup Video Resolution

    Chapter 5. Setup Video Resolution Users can setup video resolution on Video Format page of the user-friendly browser-based configuration interface. Video Configuration can be found under: Streaming> Video Configuration. The default values of video resolution are as below. H.265/H.264- 2688 x 1512 (30/25 fps) + H.265/H.264- 800 x 600 (30/25 fps)
  • Page 20: Chapter 6. Configuration Files Export / Import

    Chapter 6. Configuration Files Export / Import To export / import configuration files, users can access the Maintenance page on the user-friendly browser-based configuration interface. The Maintenance setting can be found under this path: System> Maintenance. Users can export configuration files to a specified location and retrieve data by uploading an existing configuration file to the camera.
  • Page 21: Chapter 7. Tech Support Information

    Chapter 7. Tech Support Information This chapter will introduce how to delete previously-installed Viewer in the PC and how to setup the Internet security. 7.1 Delete the Existing DCViewer This chapter will introduce how to delete previously-installed DCViewer in the PC and how to setup the Internet security.
  • Page 22 Step 3:Under <ActiveX controls and plug-ins>, set ALL items (as listed below) to <Enable> or <Prompt>. Please note that the items vary by IE version. ActiveX controls and plug-ins settings: 1. Binary and script behaviors. 2. Download signed ActiveX controls. 3.
