Wiring Diagrams
Generac PWRcell 4
Contactors
Battery String DC
I/O Switch
Module CAT5 COMs Cable
Module Jumpers
28
Black-start battery
Front
Module 1
Module 2
Back
Snubber
REbus 380v DC
REbus cable entrance
Module 3
Module 4
Installation Manual for Generac PWRcell Battery
