General Information
Serial Number Locations
Refer to
Figure 2-1
to locate unit serial number and
nameplate. Record the information from these tags so it
is available if the tags are lost or damaged. When
ordering parts or requesting assistance, you may be
asked to provide this information.
Figure 2-1. Serial Number Location
8
Unit Dimensions
A
A
0009891
B
Figure 2-2. Unit Dimensions
A
68.375 in (1737 mm)
B
22 in (558 mm)
C
9.87 in (251 mm)
Installation Manual for Generac PWRcell Battery
C
0009892
