Installing Generac PWRcell Battery
9.4 in
239 mm
1.23 in
31 mm
42.8 in
1.09 m
29.6 in
0.751 m
Figure 4-2. Generac PWRcell Battery Rear View
22.2 in
563.1 mm
Figure 4-3. Generac PWRcell Battery Front View
14
22.2 in
563 mm
13.4 in
339 mm
B
67.7 in
1.7 m
009925
251.2 mm
B
A
Figure 4-4. Generac PWRcell Battery Side View
009921
Installation Manual for Generac PWRcell Battery
9.9 in
1.3 in
29.2 mm
57.6 in
1.46 m
41.6 in
1.06 m
009924
