Shademaker Astral-TC Installation And Operating Instructions Manual page 2

(A)
1. Standrohr
2. Kunstoffring
3. Verbindungsblozen
4. Mast
5. Kurbel
6. Spannrohr
7. Zahnriemen
8. Schieber
9. Verdrehsicherungs PIN
10. Teleskoprohr
11. Seilöse
12. Polyesterseil
13. Umlenkrolle
14. Krone
15. Strebe
16. Stützstrebe
17. Scharnier
18. Stebenende
19. Überzug
20. Abspreizer
2 21 22
(C)
14.Hub
13.Pully
12.Rope
11.Bracket
1. Support tube
2. Plastic ring
3. Locking Screws
4. Pole
5. Crank Handle
6. Support pole
7. Teeth Belt
8. Runner (Slider)
9. PIN
10. Central tube
11. Bracket
12. Rope
13. Pully
14. Hub
15. Long rib
16. Short rib
17. Arm Strop (Hinge)
18. Arm End Fitting
19. Canopy
20. Spacer button
(D)
15.Long Rib
16.Short Rib
10.Central
Tube
9.Pin 20.Spacer Button
8.Runner
7.Teeth Belt
6.Support Pole
5.Crank Handle
4.Pole
3.Locking Screws
2.Plastic Ring
1.Support Tube
(E)
17.Arm Strop
18.Arm End Fitting
19.Canopy
1. Tube de fi xation
2. Bague en plasticque
3. Vis d'assemblage
4. Mât
5. Manivelle
6. Tube de serrage
7. Courroie crantée
8. Coulissau
9. PIN anti-rotation
10. Tube téléscopique
11. Oeillet de câble
12. Câble en polyester
13. Poulie de renvoi
14. Couronne
15. Balaine
16. Renfort de soutien
17. Charnière
18. Extrémité de baleine
19. Toile
20. Cosse dêcartement
(B)
