INSTALLATION INSTRUCTIONS
VOLT
Line Voltage Landscape Lighting
®
VOLT
Line Voltage Stake
®
STK-17LI-XXX
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
Specifications and product details subject to change without notice.
© Copyright 2018, VOLT
customersupport@voltlighting.com • 813.978.3700
Lighting, Lutz FL USA 33549 • All rights reserved.
®
- 1 -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Volt STK-17LI Series
Summary of Contents for Volt STK-17LI Series
- Page 1 STK-17LI-XXX Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2018, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • 813.978.3700 - 1 -...
-
Page 2: Important Safety Instructions
WARNING: RISK OF PERSONAL INJURY- This product may have sharp edges. Wear gloves to prevent cuts or abrasions when removing from carton, handling, installing and maintaining this product. VOLT Lighting assumes no responsibility for claims ® arising out of improper or careless installation or handling of this product. - Page 3 Package Contents A. (1) Stake B. (1) Grid Product Dimensions 17.32” 1” 8.26” 8.26” Install Stake and Conduit Ground Level Stabilizer Conduit Stake Grid Dig a hole in the ground for the conduit runs and the stake. Install the conduit. Slide the stabilizer grid onto the stake and secure with the screws.
- Page 4 INSTALLATION INSTRUCTIONS VOLT Line Voltage Landscape Lighting ® VOLT Line Voltage Stake ® Remove Cap from Stake Remove the cap from the stake by loosening the set screws. Set Screw Stake Install Cap to Fixture Thread the cap onto the fixture body and hand tighten until snug.
- Page 5 Wire Connection and Fixture Installation Allow enough wire from the fixture for adjustment purposes. Connect the wires from the fixture into the wiring terminal. The white wire goes to the “Neutral” terminal; the black wire goes to the “Live” Set Screw Fixture terminal;...
- Page 6 INSTALLATION INSTRUCTIONS VOLT Line Voltage Landscape Lighting ® VOLT Line Voltage Stake ® w w w . v o l t l i g h t i n g . c o m - 6 -...
- Page 7 . v o l t l i g h t i n g . c o m Specifications and product details subject to change without notice. © Copyright 2018, VOLT Lighting, Lutz FL USA 33549 • All rights reserved.
