HermanMiller Equa 2 Quick Manual

HermanMiller
Equa 2 Chair
®
Seating that
performs for you.
Seat Height: Paddle-shaped lever on right side
At the proper height, your feet should rest flat on the floor.
Tilt Tension: Knob under seat on front of chair
Set the tilt tension to control the resistance you feel when reclining.
HermanMiller Equa 2 Chair
®
To raise:
Take your weight off chair, lift lever up.
To lower:
Lift lever up while seated.
To increase:
Turn knob to the left.
To decrease:
Turn knob to the right.
Tilt Lock: Paddle-shaped lever on the left side of tilt mechanism
Only available on some models.
Engage the tilt lock when you want to sit in an upright position.
Lumbar Depth: Pump pad and release button on front of right back support
Only available on split-pad models.
Adjust the lumbar depth so that it comfortably supports the natural curve
of your spine.
1
To lock upright:
While seated upright, swing
paddle back.
To release:
Swing paddle forward.
To increase:
While seated, lift your weight off back
of chair, push pump pad in to inflate
lumbar support and achieve desired
level of support.
To decrease:
While seated, press release button to
deflate lumbar support and achieve
desired level of support.
Adjustment Guide
