Remove Cover From Child Restraint - Nuna Exec Care Instructions

Remove Cover from Child Restraint

1
- Undo the snaps on the front of the seat, being
careful not to damage the hidden white plastic
tabs.
2
- Gently begin pulling the seat cover out of the
retaining channel along the edge of the child
restraint.
3
- Unsnap the lower back seat cover from the
sides.
4
- On both sides, near the booster lap belt path,
undo the snap that secures the seat cover to
the inside of the seat.
Be careful not to damage the white plastic tab
tucked into the retaining channel at the booster
lap belt path.
5
- Unhook the white plastic tab from the button
on the edge of the seat, near the magnetic
buckle holder area.
Finish pulling the entire seat cover out of the
retaining channel.
6
- Lower the head support to the lowest position
and slide the tether strap out to completely
remove the seat cover from the child restraint.
7 EXEC care instructions
™
4 1
2 5
3
6
4 6
5 6
6 6
EXEC care instructions
™
8
