Remove Cover From Leg Rest - Nuna Exec Care Instructions

Remove Cover from Leg Rest

1
- Position leg rest with the bottom visible to
you. Locate the four tabs on the bottom of
the leg rest. Pushing each tab in the direction
indicated releases a corner of the fabric-
covered leg rest frame (detailed in step 2).
2
- While pushing in one of the four tabs (1), pull
on the fabric-covered leg rest frame at the
corner connected to that tab (2).
Tip: Start with one of the bottom corners and
use the fabric to tug the leg rest frame until it
pops out. A gentle force is necessary, so pull
straight back from the leg rest so as not to
bend or break the plastic tab.
Repeat for the other three corners. All four
corners of the leg rest frame need to be pulled
out so that the frame completely detaches from
the leg rest.
3
- Take the removable leg rest frame out of the
fabric cover and store it until you are ready to
put the seat cover back on.
Tip: The easiest way to store the frame is to put
it back into the leg rest without the fabric for
now. Align the tabs and pop it back into place.
4
- Undo black hook and loop strip under leg rest.
5 EXEC care instructions
™
1 1
2
1
2
3
4
EXEC care instructions
™
6
