To remove the power supply shield

1 To remove the power supply shield, locate and remove using a TORX T10 driver
Figure 24
Thin sheet metal parts may have sharp edges. Handle with care to avoid injury.
WARNING
2 Once the screws have been removed, carefully remove the power supply cover
6000 X-Series Oscilloscopes Service Guide
the two screws securing the shield to the rear deck.
Removing the power supply shield
by lifting the cover up and off retaining tabs on rear deck.
Replacing Assemblies
