500V 800V
IT8126-500-630 IT8126-800-
420
IT8144-500-720 IT8144-800-
480

1.2 Front-Panel Overview

For the IT8000 series Regenerative DC Electronic Load, all front panels of the
3U model are the same, and the operation panels of other models are the same
as those of the 3U model. The following is the front panel schematic of the 3U
model.
3U Model
1 Power On/Off switch
2 Vacuum fluorescent display
(VFD)
3 Function and composite keys
4 Numeric and composite keys
1500V
IT8126-1500-
210
IT8144-1500-
240
Naming rules for each series of model are as follows: IT 8XXX-YYY-ZZZ,
wherein, XXX means rated power; YYY means rated voltage; and ZZZ
means rated current.
Copyright © Itech Electronic Co., Ltd.
2250V Height
(with bare
machines
overlap-
ped)
IT8126-2250- 21U
140
IT8144-2250- 24U
160
5 Up, down, left, and right cursor navigation
keys and Enter key
6 Push-on knob
7 Vent hole
8 USB storage device connection port
Quick Reference
Height
(consti-
tuting
cabinet)
