Parts List - Linear DC2073A Demo Manual

PARTS LIST

ITEM QTY
General
1 2
2 1
3 0
4 9
5 1
6 1
7 1
8 4
DC2073A-A
1 1
2 2
3 5
4 1
5 1
6 1
DC2073A-B
1 1
2 2
3 5
4 1
5 1
6 1
DC2073A-C
1 1
2 2
3 5
4 1
5 1
6 1
DC2073A-D
1 4
2 1
3 1
4 1
5 1
DC2073A-E
1 4
2 1
3 1
4 1
5 1
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE PART DESCRIPTION
C1,C2 Cap., Chip, X7R, 10µF, 10%, 16V, 1210
C4 Cap., Chip, X7R, 1000pF, 10%, 16V, 0603
C7 OPT Cap., 0603, OPT
E1-E9 Testpoint, Turret, 0.064"
R01 Res., Chip, 49.9Ω, 1%, 0603
JP1 Headers, Dbl. Row 2 x 4 2mm Ctrs
XJP1 Shunt
(STAND-OFF) Stand-Off, Nylon 0.5"
RPOT 3/8" Square Multiturn Cermet Trimmer, 20k
RSET1, RS Res., Chip, 10k, 1% 0603
RJ1, RJ2, RJ3, RJ8, RJ9 Res., Chip, 0Ω, 0603
C5 Cap., Chip, X7R, 0.1µF, 10%, 16V, 0603
C6 Cap., Chip, X7R, 0.01µF, 10%, 16V, 0603
U1 Resistor Set SOT-23 Oscillator, SOT23, 5-Lead
RPOT 3/8" Square Multiturn Cermet Trimmer, 500k
RSET1, RS Res., Chip, 4.99k, 1% 0603
RJ1, RJ2, RJ3, RJ8, RJ9 Res., Chip, 0Ω, 0603
C5 Cap., Chip, X7R, 0.1µF, 10%, 16V, 0603
C6 Cap., Chip, X7R, 0.01µF, 10%, 16V, 0603
U1 Resistor Set SOT-23 Oscillator, SOT23, 5-Lead
RPOT 3/8" Square Multiturn Cermet Trimmer, 500k
RSET1, RS Res., Chip, 20K, 1% 0603
RJ1, RJ2, RJ3, RJ8, RJ9 Res., Chip, 0Ω, 0603
C5 Cap., Chip, X7R, 0.1µF, 10%, 16V, 0603
C6 Cap., Chip, X7R, 0.01µF, 10%, 16V, 0603
U1 Resistor set SOT-23 Oscillator, SOT23, 5-Lead
RJ2, RJ3, RJ8, RJ9 Res., Chip, 0Ω, 0603
RE Res., Chip, 1k, 1% 0603
C5 Cap., Chip, X7R, 0.1µF, 10%, 16V, 0603
C6 Cap., Chip, X7R, 0.01µF, 10%, 16V, 0603
U1 Resistor set SOT-23 Oscillator, SOT23, 5-Lead
RJ2, RJ3, RJ8, RJ9 Res., Chip, 0Ω, 0603
RE Res., Chip, 1k, 1% 0603
C5 Cap., Chip, X7R, 0.1µF, 10%, 16V, 0603
C6 Cap., Chip, X7R, 0.01µF, 10%, 16V, 0603
U1 Resistor Set SOT-23 Oscillator, SOT23, 5-Lead
DEMO MANUAL DC2073A
MANUFACTURER/PART NUMBER
Murata, GRM32DR71C106KA01
AVX, 0603YC102KAT
Mill-Max, 2308-2-00-80-00-00-07-0
Vishay, CRCW060349R9FKEA
Samtec TMM-104-02-L-D
Keystone, 8833 (Snap On)
Vishay, T93YA203KT20
Vishay, CRCW060310K0FKEA
Vishay, CRCW06030000Z0EA
AVX, 0603YC104KAT2A
AVX, 0603YC103KAT2A
Linear Tech., LTC6905CS5
Vishay, T93YA504KT20
Vishay, CRCW06034K99FKEA
Vishay, CRCW06030000Z0EA
AVX, 0603YC104KAT2A
AVX, 0603YC103KAT2A
Linear Tech., LTC1799CS5
Vishay, T93YA504KT20
Vishay, CRCW060320K0FKEA
Vishay, CRCW06030000Z0EA
AVX, 0603YC104KAT2A
AVX, 0603YC103KAT2A
Linear Tech., LTC6900CS5
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW06031K0FKEA
AVX, 0603YC104KAT2A
AVX, 0603YC103KAT2A
Linear Tech., LTC6905CS5-133
Vishay, CRCW06030000Z0EA
Vishay, CRCW06031K0FKEA
AVX, 0603YC104KAT2A
AVX, 0603YC103KAT2A
Linear Tech., LTC6905CS5-100
dc2073af
5
