Extron electronics MMK 1 Installation Manual

MMK 1/2/3 • Installation Guide
The MMK 1, 2, and 3 are a series of mounting kits meant to attach TLS and TLP touchpanels, respectively, onto a
mullion frame.

Planning

Before installing, it is important that you.
Check the installation meets the local and state regulatory requirements, including building, electrical, and safety
codes, and UL and ADA accessibility requirements.
MMK 1
D
A
B C
E
Side Front
A
B
Figure 1.
MMK 3
A
B C
E
Side Front
C
Mullion-Side End Cap
D
Mounting Screw Holes
Front and Side View of MMK 1, 2, and 3
MMK 2
A
C
B
Side E Front
D
E
Cable Opening Cover Plate
Mounting Plate Holes
D
1
