INSTALLATION INSTRUCTIONS
VOLT
®
VOLT
®
VPL-3024-BBZ
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
Specifications and product details subject to change without notice.
© Copyright 2018, VOLT
reserved. customersupport@voltlighting.com • 813.978.3700
Low Voltage Landscape Lighting
Elevator Path & Area Light
Lighting, Lutz FL USA 33549 • All rights
®
- 1 -
Advertisement
Table of Contents
Related Manuals for Volt VPL-3024-BBZ
Summary of Contents for Volt VPL-3024-BBZ
- Page 1 VPL-3024-BBZ Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2018, VOLT Lighting, Lutz FL USA 33549 • All rights ® reserved. customersupport@voltlighting.com • 813.978.3700 - 1 -...
-
Page 2: Important Safety Instructions
INSTALLATION INSTRUCTIONS VOLT Elevator Path & Area Light ® VPL-3024-BBZ Important: Please Read Before Installation This fixture is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty. - Page 3 Package Contents A. (1) Fixture Body B. (1) Extension Pole C. (1) Stake Parts Required (sold separately) A. (1) LED Lamp Product Dimensions 2.5” 2” 4” 24.5” customersupport@voltlighting.com • 813.978.3700 - 3 -...
- Page 4 INSTALLATION INSTRUCTIONS VOLT Elevator Path & Area Light ® VPL-3024-BBZ Remove Faceplate Unscrew the faceplate, then remove it from the fixture body. Faceplate Fixture Body Install/Replace Lamp Insert the lamp with the correct Lamp wattage and type marked on the fixture label.
- Page 5 Install Faceplate Screw the Faceplate back onto the fixture body. Hand tighten until snug. Faceplate Fixture Body customersupport@voltlighting.com • 813.978.3700 - 5 -...
- Page 6 INSTALLATION INSTRUCTIONS VOLT Elevator Path & Area Light ® VPL-3024-BBZ Install Stake Determine the desired location for Board mounting the fixture. Hammer the stake into the ground until the flange of the stake is flush to grade. To avoid damage to the stake, place a board on top of the stake while hammering.
- Page 7 Wire Connections Pigtail Wire Connectors Main Supply Cable Strip both leads from the luminaire pigtail. Using two wire connectors (sold seperately), connect the leads from the luminaire to the main supply cable leads. customersupport@voltlighting.com • 813.978.3700 - 7 -...
- Page 8 . v o l t l i g h t i n g . c o m Specifications and product details subject to change without notice. © Copyright 2018, VOLT Lighting, Lutz FL USA 33549 • All rights ®...
