Guldmann GH3 Series Manual

Ceiling hoist
Hide thumbs Also See for GH3 Series:
Table of Contents

Advertisement

Quick Links

GB/US . . . . GH3 Twin Ceiling Hoist
Vers . 4 .00
23W1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GH3 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Guldmann GH3 Series

Summary of Contents for Guldmann GH3 Series

  • Page 1 GB/US . . . . GH3 Twin Ceiling Hoist Vers . 4 .00 23W1...
  • Page 3 GH3 Lifting modules, version type nomenclature Guldmann Product Load in Number Number Number of Scale Service User hoist type line of lifting of lifting horizontal module module module interface straps motors drive motors None : 0 None : 0 None : 0...

  • Page 4: Table Of Contents

    GH3 Twin Ceiling Hoist Item nos: xxxx 1 .00 . . . . . . . . . Purpose and use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 1.01 .
  • Page 5 6 .00 . . . . . . . . . Classification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 7 .00 .

  • Page 6: Purpose And Use

    • The hoist is used with the Guldmann lifting hanger or with other suitable hanger (section 1.08). • The hoist is used with a Guldmann lifting sling or with other suitable slings (section 1.09). 1 .03 Important/Precautions •...

  • Page 7: Load Limits On Gh3 System

    20 min. The deflection of rails must not be higher than 1/200 of the length of the rail. – If it is not possible to do any of the above mentioned, please contact Guldmann or their representative.

  • Page 8: Power Supply

    GH3 is equipped with batteries that require regular recharging. The power supply for charging and the battery charging point must be connected by a qualified engineer or by Guldmann Service Team. The transformer supplied must always be used. Safety concerning static electricity (ESD) Service technicians and installers must use an ESD-safety package consisting of a mat, a ground wire, and a bracelet.

  • Page 9: Installation Of Gh3 Cross Lifting Hanger And Horizontal Lifter

    Installation of GH3 Cross hanger and Horizontal lifter Lifting hangers from other manufacturers Guldmann shall not be liable for faults or accidents that may occur as a result of using lifting hangers made by other manufacturers. If there is any doubt about the selection or use of a lifting hanger, please contact your supplier.
  • Page 10 2. Hold the GH3 Cross lifting hanger and press the yellow button using the thumb with the same hand that holds the hanger. (Fig. 3) Fig . 3 3. Insert the hook on the lifting beam in the slot on the Cross hanger’s top cover with the open side facing upward (Fig.

  • Page 11: Lifting Sling

    Slings made by other manufacturers Guldmann shall not be liable for faults or accidents that may occur as a result of using lifting slings made by other manufacturers. If there is any doubt about the selection or use of a lifting sling, please contact your supplier.

  • Page 12: Description Of Functions

    Attaching the lifting sling to GH3 Cross hanger Place the straps from the lifting sling on the hooks on the lifting hanger. Start with the uppermost set of straps (from the back) and then take the lowest set of straps (from the legs). Attaching the lifting sheet to Horizontal lifter, foldable Read the instructions in the user manual for the Horizontal lifter 2 .00...

  • Page 13: Pictograms

    2 .01 Pictograms Emergency stop Emergency lowering function Reset emergency stop RESET Tilt function 2 .02 Indicator lamps and audio signals Status Indicator Audio signals Possible GH3 lamps Functions – stand by All OK Green No charging Yellow, 3 x Beep after 60 sec after 15 sec Low battery Yellow...

  • Page 14: Operation

    2 .03 Operation Hand control The GH3 is switched on automatically when a button on the hand control is pressed. The GH3 is switched off automatically after approx. 8 minutes without activation. 1. Lift 2. Lower 3. Lift leader hoist. (Tilt fuction) 4.
  • Page 15 Using tilt function on GH3 The GH3 has a tilt function. This function can only be used with a horizontal lifter. (See section 2.03 for positions of hand control buttons) 1. When the buttons 1 or 2 are pressed both hoists will lift or lower the horizontal lifter.

  • Page 16: Supplementary Modules, Gh3

    2 .04 Supplementary modules, GH3 There are various supplementary modules for the GH3 • Scale module (GH3 with integrated scale) • CLM module (GH3 with statistical function for management use) • Service module (GH3 with Service module) Menu structure, Supplementary modules GH3 (Detailed description follows in sections 2.05-2.09) Scale Next service...
  • Page 17 Next service Setup 2008.04.22 Setup Units Language Language 4-8 Lifetime English Italianio total lifts Change Exit Change Change Units Language 1-8 Language 5-8 Lifetime Dansk Espanol heavy lifts Next Exit Change Change Change Units Language 2-8 Language 6-8 Last week Deutsch Francaise total lifts...

  • Page 18: Configuration Of Supplementary Modules, Gh3

    1. Press any key on the GH3 hand control to activate the hoist. When the hoist is activated, the display on the hand control is switched on and the Guldmann logo “G” appears. 2. Select “Menu” using the function key located immediately below the display and then select until the “Setup”...

  • Page 19: Scale Module (Gh3 With Integrated Scale Module)

    1. Press any key on the hand control to activate the hoist. When the lifting module is activated, the display on the hand control is switched on and the Guldmann logo “G” appears. 2. Select “Menu” using the function key located below the display 3.
  • Page 20 1. Press any key on the hand control to activate the hoist. When the lifting module is activated, a display on the hand control is switched on and the Guldmann logo “G” appears. 2. Select “Menu” using the function key located immediately below the display 3.
  • Page 21 Weighing Scale Scale 248.0 Menu Start Zero Exit 1. Always reset the GH3 scale module before weighing takes place, see section entitled “Resetting the unit”. 2. Place the lifting sling on the user and attach it to the lifting hanger. 3.

  • Page 22: Clm Module (Gh3 With Statistical Function For Management Use)

    This information can be downloaded and used for further analysis. (PDA/Net Book readouts requires a PDA/Net Book with Guldmann Service and Information consol). Number of lifts, total...
  • Page 23 Accessories for the CLM module, GH3 The CLM module includes an extended management menu which can be operated via a PDA/Net Book (with Guldmann Service and Information consol installed). The PDA/Net Book is connected to the hand control via a mini USB plug located in the base of the hand control (see section 2.04).

  • Page 24: Service Module (Gh3 With Service Module)

    1. Press any key on the hand control to activate the hoist. When the lifting module is activated, a display on the hand control is switched on and the Guldmann logo “G” appears. 2. Select “Menu” using the function key located immediately below the display.
  • Page 25 Attention! If the service date is exceeded by more than 60 days, the hoist makes an acoustic signal, at any button activation. The Acoustic signal can be disabled by the “Guldmann Service and Informa- tion Consol” software. Note: The display on the hand control will automatically revert to the screensaver...

  • Page 26: Safety Functions

    2 .09 Safety functions The emergency stop and emergency lowering device should only be used in an emergency In the event that it is necessary to use the safety functions, the fault must be identified and rectified before the GH3 is taken into use again. Please contact your supplier.
  • Page 27 Emergency lowering function, electric If the GH3 fails, the electrical emergency lowering function is used to lower the user safely. The emergency lowering function is operated by a constant pull on the red strap that is used for the emergency stop. When releasing the red strap, the emergency lowering function will be replaced by the emergency stop.

  • Page 28: Charging/Connection

    A green indicator lamp on the transformer indicates that it is connected and switched on. 2 .11 Accessories Guldmann – ABC slings and lifting hangers Obtain a brochure from your distributor, manufacturer or at www.guldmann.com Extension strap 550459 The extension strap is used where the distance between the lower part of the rails and the floor exceeds 3.5 m (11' 7").

  • Page 29: Transport And Storage

    The horizontal lifter may be used only for horizontal relocation of people lying on a level, horizontal surface. The person must be lying on a Guldmann sling or on another suitable sling. A level surface can be, for example, a bed, a stretcher or the floor.

  • Page 30: Maintenance And Storage

    Contact your supplier and order a new lifting sling or a replacement of the lifting strap. Replacement of the lifting strap must only be performed by the Guldmann Service Team or by a qualified technician in accordance with Guldmann’s instructions.

  • Page 31: Service And Lifetime

    Inspection of the GH3 must be performed by a qualified service technician or the Guldmann Service Team. In connection with the purchase of the GH3, Guldmann may offer a service agreement for this inspection. The GH3 with service module may only be serviced by the Guldmann Service Team or by a qualified service technician with access to the PDA/Net Book with Guldmann Service and Information consol.

  • Page 32: Troubleshooting

    The GH3 does not respond to the hand control’s keys 1. Check the emergency stop is not activated 2. Check the hoist has power supply 3. Check the transformer is switched on and connected to the rail system 4. Contact the Guldmann Service Team 6.00 Classification CE marking Medical equipment with respect to electrical shock, fire and mechanical hazards only.
  • Page 33 Part no. x x x x x x Edition x x x xxx kg/xxx lbs Date x x x x- x x- x x Part no. xxxxxx IP44 Edition Prod. date yyyy-mm-dd Serial no. xxxx x Barcode 128C V. Guldmann A/S www.guldmann.com...

  • Page 34: Certificates

    7.00 Certificates UL 60601-1 UL No. 305250 EN/ISO10535 HMI No. 08.49A, 09.14A, 09.15A 8.00 Technical specifications GH3 Lifting modules, version type nomenclature Guldmann Product Load in Number Number Number of Scale Service User hoist type line of lifting of lifting...
  • Page 35 Functions Lifting capacity, SWL ..... . 250 kg (550 lbs), 500 kg (1100 lbs)Operation Hand control / IR Sound level ..........52 dB (A) GH3 Twin Lifting speed 85 kg (187 lbs) load...
  • Page 36 Dimensions A ..........1800 mm (70.9 inch) B .
  • Page 37 Electronics On/off ......Automatic when used. Soft start/stop Overload protection ........Automatic Low Battery protection .

  • Page 38: Ec-Declaration Of Conformity

    9 .00 EC-Declaration of conformity EC-DECLARATION OF CONFORMITY Manufacturer V. Guldmann A/S Graham Bells Vej 21-23A DK-8200 Aarhus N EAN country code: 57 EAN distribution No.: 07287 Phone +45 8741 3100 +45 8741 3131 Representative Company Address Country Phone Hereby declare that...

  • Page 39: Usa And Countries Outside The Eu

    The warranty does not cover any part of the lifting equipment which has been altered or changed in any way by you or others. Guldmann is not responsible for problems caused by changes in the operating characteristics of the opera- ting system which are made after the delivery of the lifting equipment.
  • Page 40 Guldmann shall not in any case be liable for special, incidental, consequen- tial, indirect or other similar damages arising from any breach of these warranties even if Guldmann or its agent has been advised of the possibility of such damages.
  • Page 44 V . Guldmann A/S Corporate Office: Graham Bells Vej 21-23A DK-8200 Århus N Tel. +45 8741 3100 Fax +45 8741 3131 info@guldmann.com www.guldmann.com Guldmann Inc . 5525 Johns Road Suite 905 Tampa, FL 33634 Tel. 800 664 8834 Tel. 813 880 0619 Fax 813 880 9558 info@guldmann.net...

This manual is also suitable for:

Gh3+ seriesGh3 twin series
