Guldmann GL5 .2 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GB/US . . . . GL5 .2 mobile lifter
User manual – vers . 102 .0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GL5 .2 and is the answer not in the manual?

Questions and answers

Related Manuals for Guldmann GL5 .2

Summary of Contents for Guldmann GL5 .2

  • Page 1 GB/US . . . . GL5 .2 mobile lifter User manual – vers . 102 .0...

  • Page 2: Table Of Contents

    GL5 .2 mobile lifter Item nos: 5623xx 1 .00 . . . . . . . . . Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 2 .00 .
  • Page 3 16 .00 . . . . . . . . Environmental policy statement - V . Guldmann A/S . . . . . . .

  • Page 4: Manufacturer

    4 .00 Conditions for use The Guldmann mobile lifter GL5.2 is an all-round lifter, it can be used indoor whenever elderly and handicapped people have to be lifted or moved. The lifter is equipped with Guldmann lifting hanger or with another suitable hanger.

  • Page 5: Where To Use Gl5.2

    • The use of ACCESSORIES, transducers and cables other than those speci- fied, with the exception of transducers and cables sold by Guldmann A/S of the lifter as replacement parts for internal components, may result in incre- ased EMISSIONS or decreased IMMUNITY of the lifter.

  • Page 6: Important

    • The lifter should not be used adjacent to or stacked with other equipment and that if adjacent or stacked use is necessary, the lifter should be observed to verify normal operation in the configuration in which it will be used. •...

  • Page 7: Definitions

    6. Emergency lowering manual (option) 7. Push handle 8. Lifting actuator 9. Chassis leg 10. Brake/release Accessories can be found in the Guldmann product catalogue. 5 .01 Accessories for the lifter Lifting slings Ask for special brochure from supplier or manufacturer.

  • Page 8: Unpacking And Preparation Of The Lifter

    If the packaging is damaged on receipt, each part of the lifter must be careful- ly examined for visible defects or deficiencies. In case of suspected damage, do not use the lifter until authorized by qualified service staff or the Guldmann Service Team.
  • Page 9 Mounting of connectors for motors Start by opening cable cover by sliding down and straight out. Insert connector from the lifting actuator to port 1 (pos. 9) on the control box. Insert the cable from the lifting actuator into the cable clips (pos.

  • Page 10: Checklist Before Use

    Batteries The batteries supplied with the lifter are not fully charged on delivery. The battery pack must be charged before use. A full charge is recommended, duration approximately 4 hours. 6 .02 Checklist before use • The lifter must be off charge. •...

  • Page 11: Charging Procedure

    6 .04 Charging procedure Recharge lifter every night or when it is not in use. This maintains the batte- ries and ensures a long life span. Avoid fully discharging the battery. Recharging • Recharge by plugging the power cord (pos. 15) into a wall socket. While charging, the green LEDs on the control box are lit.

  • Page 12: Operation

    7 .00 Operation To lift/lower and adjustment of chassis leg in/out • To lift the patient press UP arrow and to lower the patient press DOWN arrow on the hand control or the control box. • On GL5.2 mobile lifter the leg spread width adjustment of the chassis is operated via the sideways arrows on the hand control.

  • Page 13: Indicator Lamps And Audio Signals

    7 .01 Indicator lamps and audio signals Status Indicator lamps Audio signals Possible GL5.2 signals Down Leg spread Emergency down Hand control Battery charged 75-100% 3 Green lights Battery charged 50-75% 2 Green lights Battery charged <50% 1 Green light Critical low battery, 1 Yellow light Beeps at button...
  • Page 14 LED 1 - LED 2 - LED 3 LED state (Not listed = off) States while charging LED 1 - 3 constantly on 90 - 100% LED 1 + 2 constantly on 65 - 90% LED 3 flashes slowly LED 1 constantly on 40 - 65% LED 2 flashes slowly LED 1 flashes slowly...
  • Page 15 States in LED state (Not PRIORITY LED 4 + LED 5 normal Comments Reset listed = off) usecharging LED 4 flashing Pairing Not ready to Wait until according to Bluetooth drive ready Bluetooth pairing state* LED 4+5 con- Emergency Not ready to Reactivate stantly on stop activated...

  • Page 16: Safety Functions

    7 .02 Safety functions Only use the emergency stop button and emergency lowering functions in emergencies. If it has been necessary to apply the emergency/safety func- tions due to an error on the lifter, the supplier must be contacted prior to using the lifter again.

  • Page 17: Use Of Mobile Lifter

    8 .01 How to use the Sling Use slings with 4-6 lifting straps designed for fitting on Guldmann lifting han- ger as shown in the sling manual. The Lifter can be positioned under a bed. It can be moved through normal doors.
  • Page 18 The lifting hanger and lifting boom should be paral- lel with the person’s shoulders. Now fit the lifting sling to the lifting hanger. For instructions on how to fit the sling, see separate Guldmann Slings manual for details.

  • Page 19: Cleaning And Disinfection

    All four straps are now ready to be mounted onto the lifting hanger. If in doubt about how to use the sling, please contact your supplier. Guldmann cannot be held responsible for any faults or accidents that may occur due to incorrect positioning of the lifting hanger, or for reasons of inade- quate attention paid by helpers or the user.

  • Page 20: Troubleshooting

    If other chemicals and/or liquids with higher resolution should be used to clean or disinfect these products, please contact Guldmann providing the item´s safety sheet chemical composition for consideration. Caution: Take great care to ensure that no liquids get inside the lift. The lift is not waterproof.

  • Page 21: Service And Lifespan

    Are the connectors for the lifting motor and/or leg adjustment motor fitted? Yes see point 5 fit connector Contact the Guldmann Service Team if the fault cannot be found and corrected. 10 .00 Service and lifespan According to the international standard EN/ISO 10535 “Lifter for the transfer of disabled persons - Requirements and test methods”...

  • Page 22: Service Check Of The Mobile Lifter - All-Round

    During the inspection a service report shall be made, describing what has been checked and exchanged. Worn or defective parts shall be replaced by new spare parts from V. Guldmann A/S. 1 Visual check of the product • Check the product for wear and tear •...

  • Page 23: Environmental Conditions

    106 kPa 40ºC 104ºF -10ºC 70 kPa 14ºF Transportation and storage The lifter can be dismantled for transport and storage. How to pack the lifter for transport Guldmann recommends that the dismantled lifter is always transported in its original packaging.

  • Page 24: Technical Specifications

    Storage of mobile lifter The mobile lifter should be stored in a dry room, where the humidity does not exceed 70%. The mobile lifter must never be stored in bathrooms and similar areas. Always activate emergency stop when the active lifter is put on storage. If the lifter is not used for a long period, it can be necessary to periodicly check or charge the battery.
  • Page 25 A ..... 69 mm B ....143 mm C .

  • Page 26: Product Configuration Table

    Acc. to ISO 9999 .........12 36 03 13.00 Product configuration table GL5.2 mobil lifter, configurations Guldmann Product Load in Castors...

  • Page 27: Labelling

    Leg adjustment Examples of labels Serial number label GL5.2 (xxxx) xxx xxx xxxx max xxx kg / xxx lbs xxxxxx Duty Cycle max: 10% 2 min/18 min xxxxx V. Guldmann A/S Graham Bells Vej 21-23A 8200 Aarhus N, Denmark yyyy-mm-dd GS1-128...
  • Page 28 Hand control Control box Battery Actuator...

  • Page 29: Eu-Declaration Of Conformity

    Class I. 16 .00 Environmental policy statement - V . Guldmann A/S Guldmann is continuously working towards ensuring that the company’s impact on the environment, locally and globally, is reduced to a minimum. It is Guldmann’s goal to: •...
  • Page 30 Tabel 2 Guidance and manufacturer’s declaration – electromagnetic immunity The GL5.2 is intended for use in the electromagnetic environment specified below. The customer or the user of the GL5.2 should assure that it is used in such an environment. IMMUNITY test IEC 60601 Compliance level Electromagnetic environment...
  • Page 31 Tabel 4 Guidance and manufacturer’s declaration – electromagnetic immunity The GL5.2 is intended for use in the electromagnetic environment specified below. The customer or the user of the GL5.2 should assure that it is used in such an environment. IMMUNITY test IEC 60601 TEST Compliance Electromagnetic environment...
  • Page 32 (the “Warranty Period”). If a valid claim is made during the Warranty Period for malfunction or equipment defect, Guldmann will repair or replace the equipment at no additional cost to you. Guldmann retains sole discretion as to whether the equipment will be repaired or replaced.
  • Page 33 Guldmann Certified Technician. A Guldmann Certified Technician is a technician who has successfully completed Guldmann Service Training, and who holds a valid Service Training Certificate from Guldmann, and is in pos- session of a valid password to access Guldmann’s Service and Information Console (SIC).
  • Page 36 V . Guldmann A/S Corporate Office: Tel. +45 8741 3100 info@guldmann.com www.guldmann.com Guldmann Inc . Tel. 800 664 8834 Tel. 813 880 0619 info@guldmann.net www.guldmann.net...
