Guldmann GH3 User Manual

Ceiling hoist
Hide thumbs Also See for GH3:
Table of Contents

Advertisement

Quick Links

See also: Manual
GB/US . . . . GH3 Twin Ceiling Hoist
Vers . 9 .00
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GH3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Guldmann GH3

Summary of Contents for Guldmann GH3

  • Page 1 GB/US . . . . GH3 Twin Ceiling Hoist Vers . 9 .00...
  • Page 2 GH3 Lifting modules, configurations Guldmann Product Load in Number Number Number of WIFI Scale Service User hoist type line of lifting of lifting horizontal module module module module interface straps motors drive motors 0 - 1 - 2 Hand control: 0...

  • Page 3: Table Of Contents

    1.07 ..Placing a new GH3 Hoist in an existing rail system ....
  • Page 4 11 .00 . . . . . . . . Environmental policy statement - V . Guldmann A/S . . . . . . .

  • Page 5: Purpose And Use

    Only technicians who have been certified by Guldmann may install and test the rail systems. • The hoist is used with the Guldmann lifting hanger or with other suitable hanger (section 1.09). • The hoist is used with a Guldmann lifting sling or with other suitable slings (section 1.10).

  • Page 6: Important/Precautions

    The red strap for the emergency stop and the emergency lowering must be adjusted to the helpers reach, and must not be removed. • The GH3 must not be used where there is a risk of it being splashed with water. •...

  • Page 7: Load Limits On Gh3 System

    Unpacking and Preparation Visual check of the GH3. If the GH3 is thought to be damaged upon reception, the GH3 must not be used before it has been checked and approved by a qualified person or the Guldmann Service Team.

  • Page 8: Power Supply

    To do this, push the yellow reset button (see point 2.09). 1 .08 Power supply GH3 is equipped with batteries that require regular recharging. The power supply for charging and the battery charging point must be connected by a qualified engineer or by Guldmann Service Team.

  • Page 9: Installation Of Gh3 Cross Hanger And Horizontal Lifter

    Installation of GH3 Cross hanger and Horizontal lifter Lifting hangers from other manufacturers Guldmann shall not be liable for faults or accidents that may occur as a result of using lifting hangers made by other manufacturers. If there is any doubt about the selection or use of a lifting hanger, please contact your supplier.
  • Page 10 Fig . 5 5. The GH3 Cross hanger is ready to use, when it is able to move freely in a horizontaI position (Fig. 6) Fig . 6 Installation of GH3 Horizontal lifter Use the oval hook to install the Horizontal lifter.

  • Page 11: Lifting Sling

    Working with the GH3 The GH3 runs easily in the rail system and does not have any special requirements for space or power in connection with moving. Attention can thus be fully focused on the user’s functional level and the helper’s technique.

  • Page 12: Description Of Functions

    2 .00 Description of functions Information panel on the GH3 bottom surface on leader hoist. Lamp indicator Information on strap Information panel on the GH3 bottom surface on follower hoist. Lamp indicator 2 .01 Pictograms Emergency stop Emergency lowering function...

  • Page 13: Indicator Lamps And Audio Signals

    2 .02 Indicator lamps and audio signals Status Indicator Audio signals Possible GH3 lamps Functions – stand by All OK Green No charging Yellow, 3 x Beep after 60 sec after 15 sec Low battery Yellow Fault on Yellow Beeps at button activation...

  • Page 14: Operation

    2 .03 Operation Hand control The GH3 is switched on automatically when a button on the hand control is pressed. The GH3 is switched off automatically after approx. 8 minutes without activation. 1. Lift 2. Lower 3. Lift leader hoist. (Tilt fuction) 4.
  • Page 15 Using tilt function on GH3 The GH3 has a tilt function. This function can only be used with a horizontal lifter. (See section 2.03 for positions of hand control buttons) 1. When the buttons 1 or 2 are pressed both hoists will lift or lower the horizontal lifter.

  • Page 16: Supplementary Modules, Gh3

    2 .04 Supplementary modules, GH3+ There are various supplementary modules for the GH3+ • CLM module (GH3+ with statistical function for management use) • Service module (GH3+ with Service module) • Scale module (GH3+ with integrated scale) Scale • Class III Scale (GH3+ with integrated Class III Scale)
  • Page 17 ervice Setup 04.22 Setup Units Language Language 4-8 English Italianio Change Change Change Units Language 1-8 Language 5-8 Dansk Espanol Change Change Change Units Language 2-8 Language 6-8 Deutsch Francaise Change Change Change Language 3-8 Language 7-8 Svenska Portuguese BR Change Change...
  • Page 18 Menu structure, GH3/GH3+ with supplementary modules • Class III Scale • CLM module • Service module Scale Scale Info 1-2 Next se Version 01.00 2008.0 Start Next Show Scale Scale Info 2-2 Lifetime 80.3 Changes total lifts Tare Exit Next...
  • Page 19 Next service Setup 2008.04.22 Setup Language Language 4-8 time English Italianio lifts Exit Change Change Language 1-8 Language 5-8 time Dansk Espanol y lifts Exit Change Change Language 2-8 Language 6-8 week Deutsch Francaise lifts Exit Change Change Language 3-8 Language 7-8 Svenska Portuguese BR...

  • Page 20: Configuration Of Supplementary Modules, Gh3

    2.05 Configuration of supplementary modules, GH3 Before the GH3 is put into use, the hoist must be configured. Configuration covers language (Scale module/CLM module/Service module) and the unit for specification of weight (Scale module). Factory setting: Language: English (UK) Unit of weight: Scale module: The weight unit can be set to kg or lb.

  • Page 21: Important Before Using The Scale Module And Class Iii Scale

    Shock effects The GH3+ with scale module includes high-sensitive sensors to register mass corresponding to the nominal recommended load. The sensors are highly sensitive and can be damaged by the effects of shock, for example pulling the GH3+ at extreme speed into an end stop.

  • Page 22: Scale Module (Gh3+ With Integrated Scale Module)

    2 .07 Scale module (GH3+ with integrated scale module) The GH3+ with scale module (option) provides the facility to determine the user’s weight. Warning! If the scale is required to comply with the Non-automatic weighing instru- ments directive (EU Directive 2014/31/EU), a Class III scale must be used.
  • Page 23 1. Press any key on the hand control to activate the hoist. When the lifting module is activated, a display on the hand control is switched on and the Guldmann logo “G” appears. 2. Select “Menu” using the function key located immediately below the display 3.
  • Page 24 Start Zero Exit 1. Always reset the GH3 scale module before weighing takes place, see section entitled “Resetting the unit”. 2. Place the lifting sling on the user and attach it to the lifting hanger. 3. Lift the user with care.

  • Page 25: Class Iii Scale (Gh3+ With Class Iii Scale)

    2 .08 Class III Scale (GH3+ with Class III Scale) Scale The GH3+ with scale module (option) provides the facility to determine the user’s weight. Start Description A Class III scale is a built-in digital scale that satisfies the requirements for...
  • Page 26 Tare Tare 1. Press any key on the hand control to activate the hoist. Guldmann logo “G” appears in the display. Select “Menu” using the function key located immediately below the display. 2. Then select until the “Scale” menu appears in the display.
  • Page 27 Weighing with a Class III scale Scale Scale 80.3 Tare Exit Tare Exit 1. Always reset the scale module before weighing. See section ”Resetting of Class III scale”. 2. Lift the lifting sling off the hanger. Place the patient in the lifting sling before mounting it on the lifting hanger.
  • Page 28 Screen utilised when using the Class III scale Start-up logo: Press ”menu” to select the function Menu Scale Menu icon for ”scale”. Press the left navigation button ”Start” to enter the menu. Start Scale Scale (in the scale menu): the scale starts up and resetting occurs automatically: - - - •...
  • Page 29 Scale Info 1-2 Version (information screen 1 of 2 in scale menu): • The number before the decimal counts the software versions and Version larger modifications 01.00 • The number after the decimal counts minor software modifications Next and bug fixes Scale Info 2-2 Changes (information screen 2 of 2 in scale menu): change counter •...

  • Page 30: Calibration/Verification Of Classe Iii Scale

    2.09 Calibration/verification of Classe III Scale In order to maintain the medical approval the digital scale must be calibrated/ verified according to national regulatory requirements at an accredited testing institute. Software version and change counter are verified on the hand control’s dis- play.

  • Page 31: Clm Module (Gh3 With Statistical Function For Management Use)

    2 .10 CLM module (GH3 with statistical function for management use) The GH3 with CLM module (option) includes a management tool that saves important information on the use of the lifting module and which can be used to evaluate the system’s efficiency and utilisation, as well as to optimise its use and hoist name/location.
  • Page 32 1. Press any key on the GH3 hand control to activate the hoist. When the lifting module is activated, the display on the hand control is switched on and the Guldmann logo “G” appears. 2. Select “Menu” using the function key located below the display.

  • Page 33: Service Module (Gh3 With Service Module)

    2 .11 Service module (GH3 with service module) The GH3 with Service module (option) saves all of the information about time and indication of next safety/service inspection. The GH3 with Service module specifies the date of the next safety/service inspection.
  • Page 34 Pop-Up’s for Service module (supplementary module) There are two different Pop-Up’s (brief messages on the display) on the GH3 with Service module. These pop-up’s notify the user of upcoming and exceeded dates for service inspections. Both Pop-Up’s appear immediately after the hand control has been switched on.

  • Page 35: Safety Functions

    GH3 Twin up to 500 kg/1100 lbs from approx. load 160 kg/350 lbs Emergency stop If the GH3 does not stop/react to the hand control when the GH3 is in use, pull the red strap and the lifting/lowering functions (except emergency lowering) are deactivated.
  • Page 36 Emergency lowering function, electric If the GH3 fails, the electrical emergency lowering function is used to lower the user safely. The emergency lowering function is operated by a constant pull on the red strap that is used for the emergency stop.

  • Page 37: Charging/Connection

    The indicator lamp on the bottom of the hoist turns yellow if the charge status becomes low or if there is a complete interruption to the charging function. The GH3 then has a limited number of lifts available at a time and must be re-charged.

  • Page 38: Environmental Conditions

    The horizontal lifter may be used only for horizontal relocation of people lying on a level, horizontal surface. The person must be lying on a Guldmann sling or on another suitable sling. A level surface can be, for example, a bed, a stretcher or the floor.

  • Page 39: Maintenance And Storage

    For long-therm storage, disconnect the battery plugs and the plug at the charging PC from the battery. 4 .03 How to prevent/avoid corrosion? When the GH3 is mainly used in an corrosive environment, e.g. swimming pool, the hoist must be ordered with a special corrosion-preventive surface treatment.

  • Page 40: The Owner's Daily Maintenance Duty

    Check the lifting sling for wear and damage before use. Do not use the lifting sling if it is damaged or defective. Do not use the GH3 if the lifting strap is damaged or defective. Contact your supplier and order a new lifting sling or a replacement of the lifting strap.

  • Page 41: Troubleshooting

    During the safety/service inspection a report must be prepared on what was checked and replaced. Parts that are worn or defective must be replaced with new parts from Guldmann. Spare parts drawings and documentation can be obtained from the manufacturer or supplier.
  • Page 42 Examples of serial number label Lifting module GH3+ xxx xxx xxxx max xxx kg / xxx lbs xxxxxx 33V AC, 2.5A, IP20 Duty cycle 2 min ON/18 min OFF x xxxx V. Guldmann A/S Graham Bells Vej 21-23A 8200 Aarhus N, Denmark...

  • Page 43: Certificates

    WIFI: 1 Class III Scale: 2 0 - 2 0 - 2 0 - 2 Twin Example: GH3+ 350 122 1000 Hand control w/o Service module w/o CLM module Scale module 2 horizontal drive motors 2 lifting motors 1 lifting strap...
  • Page 44 Covers ..Impact-resistant UL 94 V-0 flame retardant recyclable plastic Digital Scale Specifications (Non medical). Optional for GH3 Twin Capacity ..........0 – SWL Accuracy .
  • Page 45 Dimensions A ..........1800 mm (70.9 inch) B .

  • Page 46: Ec-Declaration Of Conformity

    Electronics On/off ......Automatic when used. Soft start/stop Overload protection ........Automatic Low Battery protection .

  • Page 47: Type Approval Certificate

    Graham Bells Vej 21-23A, 8200 Aarhus N DENMARK In respect of Non-automatic weighing instrument designated GH3+ with variants of modules of load receptors and load cells. Accuracy class III, single-interval or multi range (dual) Maximum capacity, Max: From 200 kg to 700 kg...

  • Page 48: Environmental Policy Statement - V . Guldmann A/S

    Guidance and manufacturer’s declaration – electromagnetic emissions The GH3 is intended for use in the electromagnetic environment specified below. The customer or the user of the GH3 should assure that it is used in such an environment. Emissions test Compliance Electromagnetic environment –...
  • Page 49 Guidance and manufacturer’s declaration – electromagnetic immunity The GH3 is intended for use in the electromagnetic environment specified below. The customer or the user of the GH3 should assure that it is used in such an environment. IMMUNITY test IEC 60601...
  • Page 50 Guidance and manufacturer’s declaration – electromagnetic immunity The GH3 is intended for use in the electromagnetic environment specified below. The customer or the user of the GH3 should assure that it is used in such an environment. IMMUNITY test IEC 60601 TEST...
  • Page 51 RF communications equipment and the GH3 The GH3 is intended for use in an electromagnetic environment in which radiated RF disturbances are con- trolled. The customer or the user of the GH3 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the GH3 as recommended below, according to the maximum output power of the communications equipment.

  • Page 52: Usa And Countries Outside The Eu

    (the “Warranty Period”). If a valid claim is made during the Warranty Period for malfunction or equipment defect, Guldmann will repair or replace the equipment at no additional cost to you. Guldmann retains sole discretion as to whether the equipment will be repaired or replaced.
  • Page 56 V . Guldmann A/S Corporate Office: Tel. +45 8741 3100 Fax +45 8741 3131 info@guldmann.com www.guldmann.com Guldmann Inc . Tel. 800 664 8834 Tel. 813 880 0619 Fax 813 880 9558 info@guldmann.net www.guldmann.net...
