parts list

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C2
3 1 C9
4 8 D5-12*
5 4 Q1-4
6 4 R1-4
7 4 R25-28
8 1 U1
Additional Demo Board Circuit Components
1 3 C3,C4,C6
2 1 C5
3 1 C7
4 1 C8
5 0 C10-21
6 4 D1-4**
7 1 D13
8 1 L1
9 9 R5-12, R24
10 1 R22
11 3 R13-15
12 1 R16
13 1 R17
14 1 R18
15 1 R19
16 1 R20
17 1 R21
18 1 R23
19 0 R29-32
20 1 U2
21 1 U3
22 1 U4
Hardware for Demo Board Only
1 12 E1-6, E8-13
2 6 E7, E14-18
3 4 J1-4
4 4 J1-4
5 1 J5
6 0 J6-8
7 1 J9
* TVS diodes are recommended for cable-driving applications.
** Substitute 0Ω resistors if diodes not desired.
DEMO MANUAL DC1880A
PART DESCRIPTION
CAP, 1µF 20%, 16V, X7R, 0603
CAP, 1µF 10%, 50V, X7R, 0805
CAP, ALUMINUM, 100µF, 20%, 63V
DIODE, TVS, 36V, SMA
TRANSISTOR, NFET, SOT-223
RES, 10Ω,1%, 0603
RES, 0.2Ω, 1%, 0805
IC, QUAD IO-LINK MASTER HOT SWAP CONTROLLER
AND PHY
CAP, 1µF, 20%, 16V X7R, 0603
CAP, 0.22µF, 10%, 16V X7R, 0603
CAP, 0.1µF, 10%, 25V X7R, 0603
CAP, TANTALUM, 4.7µF, 20%, 7343 50V
OPTIONAL
DIODE, SCHOTTKY, 1A, 100V
LED, RED
INDUCTOR, 10µH, 0.5Ω, 0.3A, 0806
RES, 100, 5%, 1206
RES, 4.99k, 1%, 0603
RES, 4.99k, 1%, 0603
RES, 100k, 1%, 0603
RES, 75k, 1%, 0603
RES, 10k, 1%, 0603
RES, 309k, 1%, 0603
RES, 59k, 1%, 0603
RES, 47.5k, 1%, 0603
RES, 680, 1%, 0603
OPTIONAL
IC, RS232 TRANSCEIVER
IC, LDO
IC, SERIAL EEPROM 2k
TURRET
TURRET
TERMINAL BLOCK, 5 POSITION, 3.5mm, HEADER
TERMINAL BLOCK, 5 POSITION, 3.5mm, PLUG
JACK, M12, 5 POSITION, FEMALE, STRAIGHT
OPTIONAL
CONNECTOR, DSUB, 9 PIN FEMALE
MANUFACTURER/PART NUMBER
TDK, C1608X7R1C105M
MURATA, GRM21BR71H105KA12L
UCC, EMZA630ADA101MJA0G
STM, SM6T36A
FAIRCHILD, FQT7N10TF
AAC, CR16-10R0FM
SUSUMO, RL1220S-R20-F
LINEAR TECH, LTC2874IFE
TDK, C1608X7R1C105M
TDK, C1608X7R1C224K
TDK, C1608X7R1E104K
AVX, TAJD475K050R
FAIRCHILD, S100
PANASONIC, LN1251C
TAIYO-YUDEN, CBC2016T100M
AAC, CR18-101JM
AAC, CR16-4991FM
AAC, CR16-4991FM
AAC, CR16-1003FM
VISHAY, CRCW060375K0FKEA
AAC, CR16-1002FM
VISHAY, CRCW0603309KFKEA
AAC, CR16-5902FM
AAC, CR16-4752FM
AAC, CR16-681FM
LINEAR TECH, LTC2802CDE
LINEAR TECH, LT3012EFE
MICROCHIP, 24LC025-I/ST
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
WÜRTH, 691321100005
WÜRTH, 691361100005
BINDER, 09-3442-500-05
SIGNATRON, DR-E9SB-NJ-001
