Page 2
No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
Page 2
No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
Page 4
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
Page 4
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
P-Fail LED will turn on and the relay output changes status for warning applications. 1.1.3 Flexible Mounting EKI-2728I is extremely compact (37 x 140 x 95 mm) and can be mounted on a DIN- rail or a panel, so it is suitable for any space-constrained environments. 1.1.4 Wide Operating Temperature The operating temperature of the EKI-2728I is between -40 ~ 75°...
P-Fail LED will turn on and the relay output changes status for warning applications. 1.1.3 Flexible Mounting EKI-2728I is extremely compact (37 x 140 x 95 mm) and can be mounted on a DIN- rail or a panel, so it is suitable for any space-constrained environments. 1.1.4 Wide Operating Temperature The operating temperature of the EKI-2728I is between -40 ~ 75°...
Relay Output: 1 Relay Output Mechanism Dimensions (WxHxD): 36.6 x 140 x 95 mm Enclosure: IP-30, Metal shell with solid mounting kits Mounting:DIN-rail, Wall Environment Operating Temperature: -40 ~ 75° C Operating Humidity: 5~95% (non-condensing) Storage Temperature: -40 ~ 85° C EKI-2728I User Manual...
Page 10
Free Fall: IEC60068-2-32 Shock: IEC60068-2-27 Vibration: IEC60068-2-6 Packing List 1 x EKI-2728I Industrial 8-port Unmanaged Gigabit Ethernet Switch 1 x Industrial Communication CD-ROM with software, and User manual 2 x Wall Mounting Bracket and Screws 1 x DIN-rail Mounting Bracket and Screws 1 x EKI-2728I Startup Manual 1 x DC Jack Cable 2.0/150mm...
Page 10
Free Fall: IEC60068-2-32 Shock: IEC60068-2-27 Vibration: IEC60068-2-6 Packing List 1 x EKI-2728I Industrial 8-port Unmanaged Gigabit Ethernet Switch 1 x Industrial Communication CD-ROM with software, and User manual 2 x Wall Mounting Bracket and Screws 1 x DIN-rail Mounting Bracket and Screws 1 x EKI-2728I Startup Manual 1 x DC Jack Cable 2.0/150mm...
LED Indicators The LED indicators located on the front panel display the power status and network status of EKI-2728I. Each of them has its own specific meaning as the tabke shown below. Table 2.1: EKI-2728I LED Definition Color Description Green On...
LED Indicators The LED indicators located on the front panel display the power status and network status of EKI-2728I. Each of them has its own specific meaning as the tabke shown below. Table 2.1: EKI-2728I LED Definition Color Description Green On...
EKI-2728I can be wall-mounted by using the included mounting kit. Then, hang on the EKI-2728I to the nails on the wall. First, use the screws included in the package to combine the EKI-2728I and metal mounting kit. And then you can install the device firmly via the components, please see Figure 2.5 as below.
EKI-2728I can be wall-mounted by using the included mounting kit. Then, hang on the EKI-2728I to the nails on the wall. First, use the screws included in the package to combine the EKI-2728I and metal mounting kit. And then you can install the device firmly via the components, please see Figure 2.5 as below.
2.3.2 DIN-rail Mounting You can also mount EKI-2728I on a standard DIN-rail by the steps as followsFirst, Note! The DIN-rail clip is screwed on the industrial switch when out of factory. If the DIN-rail clip is not screwed on the industrial switch, please screw the DIN-rail clip on the switch first.
2.3.2 DIN-rail Mounting You can also mount EKI-2728I on a standard DIN-rail by the steps as followsFirst, Note! The DIN-rail clip is screwed on the industrial switch when out of factory. If the DIN-rail clip is not screwed on the industrial switch, please screw the DIN-rail clip on the switch first.
EKI-2728I can be connected to other hubs/switches through the twisted-pair straight- through cable or the crossover cable up to 100m long. The connection can be made from any TX port of the EKI-2728I (MDI-X) to another hub or switch either MDI-X or uplink MDI port.
EKI-2728I can be connected to other hubs/switches through the twisted-pair straight- through cable or the crossover cable up to 100m long. The connection can be made from any TX port of the EKI-2728I (MDI-X) to another hub or switch either MDI-X or uplink MDI port.
If users still cannot resolve the problem, contact the local dealer for assistance. If the Industrial switch LED indicators are normal and the connected cables are correct but the packets still cannot transmit, please check your system’s Ethernet devices configuration or status. EKI-2728I User Manual...
If users still cannot resolve the problem, contact the local dealer for assistance. If the Industrial switch LED indicators are normal and the connected cables are correct but the packets still cannot transmit, please check your system’s Ethernet devices configuration or status. EKI-2728I User Manual...
Pin Assignments & Wiring It is suggested to adopt ELA/TIA as the wiring of the RJ-45. Figure A.1 RJ-45 Pin Assignments Figure A.2 EIA/TIA-568B Figure A.3 EIA/TIA-568A EKI-2728I User Manual...
Pin Assignments & Wiring It is suggested to adopt ELA/TIA as the wiring of the RJ-45. Figure A.1 RJ-45 Pin Assignments Figure A.2 EIA/TIA-568B Figure A.3 EIA/TIA-568A EKI-2728I User Manual...
