Provisioning
Table 6. H2TU-C-319 List 4E ADC Config Menu Options (Continued)
Front-Panel
ADC Config Menu
Display
Options
Code
Minor Alarm ALM
Network AIS Signal NAIS
Performance Report PRM
Messaging
SF RAI to SF RAI-CI RACI
Toward Network
See "SF RAI to SF
RAI-CI Toward
Network (RACI)
Option" on page 23.
ESF RAI to SF RAI ROVR
Overwrite
See "ESF RAI to SF
RAI Overwrite
(ROVR) Option" on
page 23.
H2TU-R DS1 Frame CONV
Conversion
See "H2TU-R DS1
Frame Conversion
(CONV) Option" on
page 23.
Fractional T1 Mode FT1
See "Fractional T1
(FT1) Option" on
page 26.
20
Selection Description
ENA Enables the generation of the output alarm on pin H when a system alarm
condition occurs.
DIS Disables the generation of the output alarm on pin H when a system alarm
condition occurs.
CI If ALMP is set to AIS, this option specifies which pattern is sent to the network
when a remote LOS or AIS occurs. When configured for CI, an AIS-CI pattern
is sent to the network.
AIS When configured for AIS, an AIS pattern is sent to the network.
SPRM The H2TU-R generates Supplemental PRM (SPRM) every second if no PRM
is received from the CPE within 5 seconds of a reset or if an LOS/AIS/LOF
condition occurs. TL1 commands and responses are enabled.
NPRM The H2TU-R generates Network PRM (NPRM) if no PRM is present from the
CPE. If the CPE is sending PRMs, NPRM is generated every second in addition
to the existing PRM. TL1 commands and response are enabled.
S + N The H2TU-R generates an NPRM which is tagged onto an SPRM every
second. The H2TU-R generates SPRM if no PRM is present from the CPE. If
the CPE is sending PRM, the PRM is converted to an SPRM. TL1 commands
and responses are enabled.
OFF ESF Datalink (DL) is completely transparent. No PRMs are generated. There
are no TL1 responses unless the system is first armed by a TL1 command,
which enables performance monitoring.
ENA Allows a DS1 SF-RAI (yellow alarm) signal received by the H2TU-R to be
converted to an SF-RAI-CI signal toward the network.
DIS Prevents conversion of the DS1 SF-RAI to SF RAI-CI. It does not prevent SF
RAI-CI to ESF RAI-CI from occurring when FCON is active.
ENA If the CONV option is set to FCON or ACON, an ESF DS1 payload from the
network with an embedded RAI pattern is converted to an SF-RAI pattern
toward the CI at the H2TU-R.
DIS Prevents conversion to an SF-RAI pattern.
ACON Auto (ACON) detection of framing and potential frame conversion at the
remote.
OFF Framing determined by the DS1 frame formatting option.
FCON Auto detection of framing and forced frame format conversion (FCON) at the
H2TU-R.
ENA Enables system response to DDS latching loopback commands for fractional
T1 applications and enables CPE disconnect or trouble indication. See
Figure 30 on page 54
DIS Disables system response to DDS latching loopback commands for fractional
T1 applications and CPE disconnect or trouble indications.
January 9, 2002
for LOS/AIS response priorities.
LTPH-UM-1049-02, Issue 2
Continued
