Provisioning
Table 5 describes the Standard Config screen options and lists their front-panel display codes.
describes the ADC Config screen options and lists their front-panel display codes. Selections in bold typeface are
the factory default settings.
Front-Panel
Standard Config
Display
Menu Options
Code
Loopback Timeout LBTO
Loop Attenuation LATT
Threshold
Margin Threshold MARG
DS1 Frame FRMG
Formatting
DS1 Line Coding DS1
H2TU-C Equalization EQL
See "H2TU-C
Equalization (EQL)
Option." on page 22.
H2TU-R Line RLBO
Buildout
Alarm Pattern ALMP
See "Alarm Pattern
(ALMP) Option." on
page 22.
H2TU-R TLOS TLOS
Loopback
Power Back Off PBON
Network
18
Table 5. H2TU-C-319 List 4E Standard Config Menu Options
Selection Description
NONE Disables automatic time-out cancellation of all loopbacks.
20 Sets automatic cancellation of all loopbacks to 20 minutes after initiation.
60 Sets automatic cancellation of all loopbacks to 60 minutes after initiation.
120 Sets automatic cancellation of all loopbacks to 120 minutes after initiation.
0 through Determines the maximum loop attenuation before an alarm is declared. Zero
40 dB disables the alarm. The loop attenuation threshold can only be set through the
maintenance screens.
32 dB Default value. Zero disables the alarm.
0 to 15 dB Determines the minimum allowable margin below which a system alarm can
occur. Zero disables the alarm.
The Margin Alarm Threshold can only be set through the maintenance
screens.
5 dB Default value.
AUTO Configures the line unit to operate in an auto-framing (AUTO) mode.
It detects and locks to both SF or ESF DS1 frame patterns. Line and path
performance parameters are maintained and displayed. Unframed payloads
will cause the ES-P and SES-P counters to increment.
UNFR Configures the same as AUTO except unframed payloads do not cause the
ES-P and SES-P counters to increment.
B8ZS Places both the H2TU-C and H2TU-R into their B8ZS modes.
AMI Places both the H2TU-C and H2TU-R into their AMI modes.
0 ft Sets the Equalizer to DSX-1 for 0 to 132 feet.
133 ft Sets the Equalizer to DSX-1 for 133 to 265 feet.
266 ft Sets the Equalizer to DSX-1 for 266 to 398 feet.
399 ft Sets the Equalizer to DSX-1 for 399 to 532 feet.
533 ft Sets the Equalizer to DSX-1 for 533 to 655 feet.
0 dB Sets the DS1 RLBO level toward the Customer Interface (CI).
-7.5 dB Sets the DS1 RLBO level toward the CI to -7.5 dB.
-15 dB Sets the DS1 RLBO level toward the CI to -15 dB.
AIS Enables the HiGain HDSL2 system to output an AIS payload at its DS1 ports
for LOSW and LOS DS1. For priority resolution, see
LOS/AIS response priorities.
LOS Enables the HiGain HDSL2 system to output an LOS condition at its DS1 ports
for LOSW and LOS DS1.
ENA Enables a logic loopback at the H2TU-R when an LOS occurs at its DS1 input,
if enabled at the H2TU-R. For priority resolution, see
DIS Disables TLOS logic loopback.
DEF Configures the power output levels of the H2TU-C network unit towards the
customer to comply with the Default template as defined in Section 6.1.4.2 of
ANSIT1.E1.4.
ENH Configures the power output levels of the H2TU-C network unit towards the
customer to comply with the Enhanced template as defined in Section 6.1.4.2
of ANSIT1.E1.4.
January 9, 2002
LTPH-UM-1049-02, Issue 2
Table 6 on page 19
Figure 30 on page 54 for
Figure 30 on page 54.
Continued
H2TU-C-319 List 4E
