- Page 1 INSTALLATION GUIDE KPF-2110 Single Lever Kitchen Faucet With Pull-Out Sprayer www.kraususa.com I Toll Free: 1.800.775.0703 I © 2017 Kraus USA Inc. I REV. August 7, 2017...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep teh box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 3: Prior To Installation
Wrap all threaded connections with Teflon tape. Always wrap in a clockwise direction • Cover your drain to avoid losing parts • Do not disassemble the main faucet body, as it has been factory assembled by Kraus for stress-free installation. • Using condition: Working pressure at 0.05-1.0MPa (including cold & hot water pressure) with applicable water temperature: 40C-900C •... -
Page 4: Included Parts
KPF-2110 Diagram and Parts List Included Parts: 1. Index Button 2. Set Screw 3. Handle 4. Cartridge Cover 5. Locking Nut 6. Cartridge 7. O-Ring 8. Faucet Body 9. Spray Head 10. Hose 11. Plastic Cover 12. O-Ring 13. Noise Silencer 14. -
Page 5: Dimension Drawings
Dimension Drawings 225 mm 225 mm (8.86”) (8.86”) 8 7/8” Ø 63 mm Ø 63 mm (2.48”) (2.48”) 2 1/2” Y 7/16 X 24 Y 7/16 X 24 G1/2 G1/2 G1/2 G1/2 Safety Tips • If soldering the water connections when installing the faucet, remove the O-rings, cartridges, and washers before applying any heat •... - Page 6 Dimension Drawings Y 7/16 X 24 G1/2 G1/2 Safety Tips • Do not overtighten fixing screws/nuts. Tighten finger-tight, then use a wrench/ screwdriver to tighten the fixing screw/nut until snug...
- Page 7 Faucet Installation Procedures Step 1 Remove metal nuts (22a and 22b) Ø35mm (Ø 1 3/8 “) from end of mounting pipe 22 a+b Span Tool Screwdriver Step 2 Insert hose (10) into faucet body (8) and through plastic base hose ring (21) Screwdriver...
- Page 8 Screwdriver Step 3 Insert faucet body (8) on pre-drilled hole 1-3/8” Ø35mm (Ø 1 3/8 “) Screwdriver Step 4 Install faucet extender (18), rubber u-washer (19), and metal u-washer (20) on mounting pipe until it touches base of countertop. Place metal nut (22a) onto mounting pipe and tighten with provided spanner (29) until snug Installer Tip: Screwdriver can...
- Page 9 Step 5 Place metal nut (22b) on mounting pipe and tighten with provided spanner until snug underneath countertop Spanner Spanner Tool Spanner Tool Tool Screwdriver Screwdriver Step 6 Screwdriver Secure extending pipe (23) on mounting pipe and tighten with provided spanner (29) until snug Spanner Tool...
- Page 10 Step 7 Secure check valve assembly (24) onto extending pipe (23). Tighten with adjustable wrench until snug Installer Tip: Check if O-rings are installed in check valve assembly (24) before installing hose (10) Step 8 Secure end of hose (10) onto check valve assembly (24) and tighten with adjustable wrench until snug Spanner...
- Page 11 Step 9 Install weight (25) at lowest point (vertically) on hose (10) and tighten screws (26) with Phillips head screwdriver Step 10 Connect hot & cold waterlines (27) to faucet (hot: long & cold: short), and install them on angle stops. Tighten with adjustable wrench until snug Installer Tip: Check if O-rings are installed on both ends of...
- Page 12 Step 11 Turn faucet on while holding tip of hose (10) to flush any debris Step 12 Secure the spray head (9) onto hose (10) and hand-tighten only Installer Tip: Check if O-ring is visible in hose (10) prior to reinstalling spray head (9)
-
Page 13: Troubleshooting
Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: P R O B L E M C A U S E A C T I O N Leakage under the Locking nut has come Loosen the set screw with a hex... - Page 14 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 15 International shipping fees are not included. COMMERCIAL WARRANTY Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied, are given, including but not limited to any implied warranty of merchantability or fitness for a particular purpose.
- Page 16 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
