Headphone Port - CYBEX 750C Addendum To Manual

Audio Visual (AV) Key Pad – Optional
Figure 2
Console Key
EPG
CHANNEL
VOLUME
VIDEO SOURCE
VIDEO PORT
USB PORT
HEAD PHONE PORT
Cybex 750C/750R Total Access (TA) Addendum
Description
If an Electronic Program Guide (EPG) is available, this will be displayed on
the TV. Use the CHANNEL Λ V and VOLUME
EPG, Enter to accept any selections.
Toggle down or up to change channel (beeping will occur).
Press appropriate keys to increase or decrease volume. There is no display
interaction.
Press to toggle between video source A for cable channels and video
source B for external inputs, such as iPod
Video capable port allows personal entertainment device or other
composite video input.
Universal Serial Bus (USB) allows different devices to be connected using a
single standardized interface port for charging only.
Head phone port allows personal headphones.
< >
keys to navigate in the
®
video.
1 – Video 3 – Left
2 – Ground 4 – Right
Operation
Page 3–5
