ADEEPT Hexapod Manual page 44

6 legs spider robot kit for arduino uno r3
Hide thumbs
Table of Contents

Advertisement

Assemble the following components
Effect diagram after assembling
+
M3*16 screw
X1
M3*8 screw
X2
Front view
The position of the
nylon standoff.
42
www.adeept.com
M3
lock nut
X1
M3*15
Nylon Standoff
X1
Side view
Note: do not tighten
the M3 lock nut or it
cannot move.
