ADEEPT Hexapod Manual page 39

Assemble the following components
Effect diagram after assembling
Note: The LED module has an
input (IN) with a white edge and
an output (OUT) without white
edge. If the LED does not light up
in yellow normally, then check if
the input and output are
reversed.
37
www.adeept.com
M1.4*6 screw
X4
3-
Pin Wire
X2
