User Manual
COLOR VIDEO DOOR PHONE
CDV-70A, 70AM, 70AD, 70AMD
• Thank you for purchasing COMMAX products.
• Thank you for purchasing COMMAX products.
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
instructions to use a product exactly.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Commax CDV-70A
Summary of Contents for Commax CDV-70A
-
Page 1: User Manual
COLOR VIDEO DOOR PHONE CDV-70A, 70AM, 70AD, 70AMD • Thank you for purchasing COMMAX products. • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow •... -
Page 2: Table Of Contents
3. Save visitor’s image & setup .............. 7 4. Installation and wiring ..............10 5. Components..................11 6. Specification ..................12 Note : The function of "Save visitor" image & setup”(page 7) is available for CDV- 70AM/CDV- 70AMD only. CDV-70A/CDV-70AD doesn't feature to save visitor's image. -
Page 3: Warnings And Caution
Warnings and caution Make sure to follow the instructions to prevent any danger or property losses. It indicates prohibition. It indicates prohibition of disassembly. Warning Death or serious It indicates prohibition of contact. injury is expected. It indicates dos and don’ts. It indicates that the plug should be pulled out from the socket. - Page 4 Secure the enough space and If the product generates strange stable place. view to unplug the power plug sound, make sure to pull the Otherwise, it may not function easily expected plug immediately and contact properly. emergency situation. Commax service center.
-
Page 5: Product Overview
1. Product overview No. Description No. Description No. Description 1 Speaker 7 Door Release button 13 Screen resolution Button 2 On/Off & display LED 8 MIC 14 Screen resolution Button 3 Monitoring button(Record images) 9 Volume control button 15 On/Off switch 4 Interphone button 10 Callingsoundlevel control button 16 DC power terminal 5 Talk button... -
Page 6: Operation Methods
* Volume control button: It is to adjust talking volume from counter side. * Calling sound level control button: It is to adjust calling sound * Screen resolution Button: It is to adjust image resolution. * DIP switch for camera setting: It is to set up the availability of door camera. Please place it “up”... - Page 7 ● Priority talk - conversation from the door camera, pressing and holding the “PTT” button will deliver only the voice of the speaker from the CDV-70A,70AM / CDV-70AD,70AMD to the door camera unit to help clarify speech. ● Adjustment of image resolution To adjust brightness or color resolution, use the buttons on the right side.
-
Page 8: Save Visitor's Image & Setup
3. Recording visitors image and setup. NOTE : Following function of “Recording visitors’ image & setup” is available for CDV- 70AM / CDV-70AMD only. For CDV-70A / CDV-70AD it is not available one. 3-1. Recording visitors’ image Press and hold the “monitoring” button (REC) for 1 second under “talk” or “monitor”... - Page 9 In case of that there is no image recorded, “No Image” appears on the screen. Area “A” on above-picture, there are operation button. Press “Del” button to remove the image displayed. Note : PREV – Previous menu UP/DN - Move the cursor up and down DEL - Remove the image.
- Page 10 3-2-3 Auto Record Setting Select “Auto Record Setting” menu to automatically save visitors’ images while you are away. Menu PREV Auto Record Setting Auto record setting Note : It shall be set as a “Auto Record” mode from manufacturer. When the visitors call, every visitor automatically is recorded 1 by 1. Maximum 128 cuts can be saved.
-
Page 11: Installation And Wiring
4. Installation & wiring method. 1) Installation diagram - Terminal wiring in rear 2) Wiring diagram CDV-70A / CDV-70AM PROGRAM... -
Page 12: Components
5. Components Monitor Wall bracket Manual A D A P T E R Power supply(17V 1.3A) T4 X 18 M3 X 6 Connector (Only CDV-70AD / CDV-70AMD) Wall bracket Monitor (4PX3 EA) Mounting Screw Fixing Screw... -
Page 13: Specification
Image recording (CDV-70AM) MAX 128 Cuts HANDS FREE type (Voice Switch) Communication way Display 17.78Cm(7”) COLOR TFT-LCD COMMAX chime : 2 times Call sound Interphone : Electric chime Stand-by : 30 seconds, Video duration time On the line : 60 seconds Entrance: 50m (Ø0.65) - Page 14 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133 Web site : www.commax.com PM0770A00011 Printed In Korea / 2013.11.104...
